Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Two-Bolt Flange Mount Bearing Unit – 1-1/2 in Bore, Reinforced Polyamide, Setscrew Lock, Closed End Cap$66.98
Two-Bolt Flange Bearing Unit – 1-1/2 in Bore, Polymer Washdown Housing, D-LOK Clamp Collar, Non-Expansion$83.93
Two-Bolt Flange Mount Bearing Unit, 1 in Bore, Eccentric Collar Locking, Wide Inner Race, Cast Iron$32.02
2-Bolt Alignable Flange Ball Bearing Unit 3/4" Bore, W200E Series, Type E Seals, Cast Iron$33.98| MFR / Brand | Link Belt |
|---|---|
| MPN | KFXSS224DC |
| Model | KFX-SS-224-DC |
| ID | 1.5 in |
| Material | Stainless Steel |
|---|---|
| Series | KFX |
| Type | Flanged Mount Bearing |
| Lubricant | Grease |
| Bolt Center To Center | 5.67 in |
| Number Of Bolt Holes | 4 |
| Bolt Center To Center Length | 5.67 in |
| Number Of Bolt Holes For Fasteners | 4 |
| Min Temp | -20 °C |
| Dynamic Load Rating | 29.5 kN |
| Static Load Rating | 19.8 kN |
| Precision Rating | ABEC 1 / P0 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Bearing Type | 4-Bolt Flange Unit |
| Item Weight | 2.80 lbs |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Internal Clearance | CN |
| Duty Type | Standard Duty |
| Locking Device | Set Screw |
| Insert Outer Ring | Spherical |
| Relubrication Feature | Yes |
| Harmonization Code | 8483.20.40.40 |
| Housing Material | Stainless Steel |
| Expansion Type | Non-Expanding |
| Limiting Speed | 5000 rpm |
| Cross Reference 1 | SKF FY 1.1/2 TF |
|---|---|
| Cross Reference 2 | Dodge F4B-SC-108 |
