Super Precision Angular Contact Ball Bearing 75x115x20 mm, Duplexable, Medium Preload — ONE Bearing (Half of a Pair)$84.12
Super-Precision Angular Contact Ball Bearing - 75 mm Bore x 115 mm OD x 20 mm Width, Open, 15 Degree Contact Angle, ABEC 5$86.99
Super-Precision Angular Contact Bearing, 75x115x20 mm, 15°, P4A$97.87
Angular Contact Ball Bearing - 75 mm Bore, 115 mm OD, 20 mm Width, Open, 15° Contact Angle, Phenolic Outer-Ring-Guided Cage, ABEC 5$98.46| MFR / Brand | SNFA |
|---|---|
| MPN | EX75-9CE1DUF |
| Model | 2MMX-9115 DUM / 7015C DUM / EX 75-9 CE 1 DUF/DUH |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 75 mm |
| OD | 115 mm |
| Width | 20 mm |
| Material | Chrome Steel |
|---|---|
| Series | EX |
| Min Temp | -30 °C |
| Cage Type | Machined |
| Dynamic Load Rating | 47.5 kN / 10678 lbf |
| Static Load Rating | 50.5 kN / 11353 lbf |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 1.8 lbs |
| Cage Material | Phenolic |
| Limiting Speed | 13000 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal |
| Cross Reference 1 | 7015CTDUHP4 |
|---|
Angular contact bearings – 75 mm ID, 115 mm OD, 20 mm Width, Open, 15°, Heavy Preload.
$227.83
45 in stock
$53.53
48 in stock
$73.22
35 in stock
