This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Banded Ball Thrust Bearing - 40 mm ID, 72.6 mm OD, 21.38 mm Height, Open$32.94
Thrust Ball Bearing - 60 mm ID, 85 mm OD, 17 mm Height, Single Direction, Open$35.40
Double Direction Thrust Ball Bearing - 40 mm Bore, 78 mm OD, 39 mm Height, Flat Housing Washers, Five-Piece Separable$42.49
Thrust Ball Bearing — Single Direction, 25 mm ID, 58 mm OD, 29.808 mm Height, Machined Brass Cage$47.71| MFR / Brand | SKF |
|---|---|
| MPN | 52205J9 |
| Model | 52205 J9 |
| ID | 20 mm |
| OD | 47 mm |
| Width | 28 mm |
| Dynamic Load Rating | 26.5 kN / 5957 lbf |
|---|---|
| Static Load Rating | 50.0 kN / 11240 lbf |
| Lubricant | Oil |
| Precision Rating | ABEC 1 / P0 |
| Series | 52200 |
| Max Temp | 120°C |
| Min Temp | -30°C |
| Rolling Elements | Balls |
| Bearing Type | Thrust Ball Bearing, Open |
| Item Weight | 0.48 lbs |
| Limiting Speed | 3800 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Contact Angle | 90° |
| Cage Type | Pressed Steel |
| Cross Reference 1 | FAG 52205 |
|---|---|
| Cross Reference 2 | NTN 52205 |
| Cross Reference 3 | KOYO 52205 |
| Cross Reference 4 | NSK 52205 |
| Cross Reference 5 | SNR 52205 |
Thrust Ball Bearing – 20 mm ID, 47 mm OD, 28 mm Width, Double Direction
$26.58
199 in stock
