This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Spherical Roller Bearing, Double Row, 70 x 125 x 31 mm, 1:12 Tapered Bore, Steel Window Cage, W33 Lubrication Groove, C3 Clearance, Open, 1 Pc$64.17
Spherical Roller Bearing - Tapered Bore, 80 mm ID, 140 mm OD, 33 mm Width, Open, C3 Internal clearance.$83.36
Double Row Spherical Roller Bearing 70 x 150 x 35 mm, Straight Bore, Steel Cage, C3, W33$90.08
Spherical Roller Bearing - Straight Bore, 220 mm ID, 340 mm OD, 118 mm Width, Open, Machined Brass Cage, CN Internal Clearance$950.57| MFR / Brand | Timken |
|---|---|
| MPN | 23060KEMBW507C08C3 |
| Model | 23060 K E MB W507 C08 C3 / 23060 K EMB W33 P5 C3 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 300 mm |
| OD | 460 mm |
| Width | 118 mm |
| Series | 23000 |
|---|---|
| Material | Bearing Steel |
| Min Temp | -30 °C |
| Cage Type | Machined |
| Dynamic Load Rating | 2160 kN / 486000 lbf |
| Static Load Rating | 3250 kN / 731000 lbf |
| Precision Rating | ABEC 1 / P0 |
| Rolling Elements | Spherical Rollers |
| Max Temp | 200 °C |
| Item Weight | 165 lbs |
| Cage Material | Brass |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Snap Ring Included | Without Snap Ring |
| Relubrication Feature | Yes |
| Harmonization Code | 8482.30.00 |
| Internal Clearance | C3 |
| Limiting Speed | 1100 rpm |
| Maximum Permissible Misalignment | 2° |
| Cross Reference 1 | SKF 23060 CCK/C3W33 |
|---|---|
| Cross Reference 2 | FAG 23060-E1-K-C3 |
| Cross Reference 3 | NTN 23060EAKD1C3 |
Timken 23060KEMBW507C08C3 is a high capacity spherical roller bearing built for demanding industrial applications. With a 300 mm bore, 460 mm outer diameter, and 118 mm width, it delivers robust support for heavy radial and axial loads while maintaining smooth motion. The open design features a machined brass cage that supports reliable operation and easy relubrication, helping to extend service life in challenging environments.
Key performance traits include a dynamic load rating of 2160 kN and a static load rating of 3250 kN, along with internal clearance class C3 for better handling of misalignment and mounting tolerances. Constructed from durable bearing steel with a brass cage, this unit is engineered for resilience across a wide temperature range from -30 to 200 degrees Celsius. The bearing weighs approximately 165 pounds, suitable for large power transmission and automation systems.
Cross references to SKF, FAG, and NTN confirm compatibility with common replacement parts, making this Timken bearing a reliable choice for industrial automation, heavy machinery, and motion control. Made in the United States, it is a trusted component for long-lasting performance in demanding settings.
