SNR22214VDouble-Row Spherical Roller Bearing – 70 mm Straight Bore, 125 mm OD, 31 mm Width, Open, CN Clearance

Product Description

What this part is: SNR 22214V double-row spherical roller bearing. Series: 22200. Base Number: 22214. Bore: 70 mm. Outside Diameter: 125 mm. Overall Width: 31 mm. Bore Type: Straight. Closure Type: Open. Number Of Rows: 2. Rolling Elements: Spherical Roller. Cage Material: Steel. Internal Clearance: CN. Precision Rating: ABEC 1 / P0. Bearing Material: Bearing steel. Operating Temperature Range: −40 °C to 200 °C. Harmonization Code: 8482.30.00.40. Searchable variants of the number: 22214V, 22214.V, 22214-V, 22214 V, 22214J, 22214CJ, 22214CCJ. Decoding the designation: Series: 22200 — the wide double-row spherical roller series. V: internal design modification. The bore is straight and cylindrical, so the inner ring seats directly on the shaft. No clearance suffix, so the clearance is CN, the normal radial class. What these specs mean in practice: Two rows of barrel rollers run on a common spherical raceway in the outer ring, so the inner ring and roller set swivel inside the outer ring. Permissible Misalignment: 0.5° at normal load, which absorbs shaft deflection and housing bore misalignment. The 22200 series is the wide section of the spherical roller range and carries a higher radial rating than the 21300 section on the same bore. The double-row arrangement takes axial load in both directions alongside the radial load. CN clearance suits a shaft-mounted fit at ambient running temperature. Quantity and configuration: Unit Quantity: 1 Pc. Single bearing, open on both faces, straight bore. Interchange guidance: Same 70 x 125 x 31 mm envelope with a straight bore: SKF 22214 E, FAG 22214-E1, NTN 22214EAW33, NSK 22214EAE4, Koyo 22214RHR, Timken 22214EJ. Load ratings and cage execution differ between makers. The NTN, NSK, Koyo and Timken numbers listed carry a W33 lubrication groove and three radial feed holes in the outer ring.
