Angular contact ball bearing, 90 x 160 x 30 mm, 15° contact angle, ISO 72 series. SKF 7218 CTC C78 G20 US-designation execution, single row, open.
List Price
$211.30
Out of stock
Out of stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Angular Contact Ball Bearing - 90 mm ID, 160 mm OD, 30 mm Width, 15° Contact Angle, Open$212.54
Angular Contact Ball Bearing - Straight Bore, 90 mm ID, 160 mm OD, 30 mm Width, Open, 15 Degree Contact Angle, Universally Matchable Single, Light Preload, Laminated Phenolic Cage$250.67
Angular Contact Ball Bearing, Super Precision Single Universal — NSK 7218CTYSULPA7, 90x160x30 mm, 15° Contact Angle$372.07
Angular Contact Ball Bearing Matched Pair - Straight Bore, 90 mm ID, 160 mm OD, 30 mm Width, Open, 15° Contact Angle, Medium Preload$705.89| MFR / Brand | SKF |
|---|---|
| MPN | 7218CTCC78G20 |
| Model | 7218 C TC C78 G20 / 2M218WI CR |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 90 mm |
| OD | 160 mm |
| Width | 32 mm |
| Condition | New – Open box |
|---|---|
| Condition Note | Made In USA, New Old Stock |
| Mpn Variants | 7218CTCC78G20, 7218 CTC/C78G20, 7218-CTC-C78-G20, 7218C, 2M218WICR |
| Series | 7200 |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Cylindrical |
| Snap Ring Included | No |
| Contact Angle | 15° |
SKF 7218CTCC78G20 is a single-row angular contact ball bearing in the ISO 72 dimension series. Bore Diameter: 90 mm. Outside Diameter: 160 mm. Width: 30 mm. Contact Angle: 15°.
7218 — single-row angular contact ball bearing, ISO 72 series, 90 mm bore (18 x 5).
C — 15° contact angle.
Contact Angle: 15°. Bore Type: Cylindrical. Number Of Rows: 1. Rolling Elements: Ball. A 15° angle favours speed and radial stiffness, carrying axial load in one direction per bearing.
Unit Quantity: 1 Pc. Open bearing. New old stock.
Common search terms for this size: 7218C, 7218 C TC C78 G20, 2M218WICR.
