Angular Contact Ball Bearing - 40 mm ID, 80 mm OD, 18 mm Width, Open, 15° Contact Angle, ABEC 7 / P4, Light Preload.$45.89
Angular Contact Ball Bearing - 40 mm ID, 80 mm OD, 18 mm Width, Open, 40° Contact Angle.$32.28
Angular Contact Ball Bearing - 40 mm ID, 80 mm OD, 18 mm Width, Open, 25° Contact Angle, P0.$42.05
Angular Contact Ball Bearing - 40 mm ID, 80 mm OD, 18 mm Width, Open, 15° Contact Angle, Light Preload.$68.06| MFR / Brand | RHP |
|---|---|
| MPN | 7208TSULP6 |
| Model | 7208-T-SUL-P6 / 7208-B / MM208 WI CR DUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 40 mm |
| OD | 80 mm |
| Width | 18 mm |
| Material | Steel |
|---|---|
| Series | 7200 |
| Preload | Light |
| Min Temp | -30 °C |
| Cage Type | Machined |
| Dynamic Load Rating | 35.5 kN / 7980 lbf |
| Static Load Rating | 23.2 kN / 5220 lbf |
| Precision Rating | ABEC 3 / P6 |
| Rolling Elements | Balls |
| Max Temp | 120 °C |
| Item Weight | 0.81 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Mounting Arrangement | Single Universal |
| Limiting Speed | 9500 rpm |
