Super-Precision Angular Contact Ball Bearing - Straight Bore, 80 mm ID, 125 mm OD, 22 mm Width, Open, 15° Contact Angle, Heavy Preload, Universal Duplex, ABEC 7$202.26
Angular Contact Ball Bearing - Straight Bore, 80 mm ID, 125 mm OD, 22 mm Width, Open, 15° Contact Angle, Single Universally Ground.$220.62
Angular Contact Ball Bearing – 80 mm ID, 125 mm OD, 22 mm Width, 15° Contact Angle, Heavy Preload, Phenolic Cage, ABEC 7/9$221.84
Super-Precision Angular Contact Ball Bearing - 80 mm ID, 125 mm OD, 22 mm Width, ABEC 7 / P4, Phenolic Cage, Universally Ground Duplex, Light Preload$76.47| MFR / Brand | RHP |
|---|---|
| MPN | 7016TDUHP4 |
| Model | 7016 T DUH P4 / MM9116WI CR DUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 80 mm |
| OD | 125 mm |
| Width | 22 mm |
| Material | Chrome Steel |
|---|---|
| Series | 7000 |
| Preload | Heavy preload |
| Min Temp | -30 °C |
| Cage Type | Machined |
| Dynamic Load Rating | 53.5 kN / 12027 lbf |
| Static Load Rating | 55.5 kN / 12476 lbf |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 1.9 lbs |
| Cage Material | Phenolic |
| Limiting Speed | 12000 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal |
| Cross Reference 1 | SKF 7016 CD/P4ADGC |
|---|---|
| Cross Reference 2 | FAG B7016-C-T-P4S-DUH |
Angular contact bearings – 80 mm ID, 125 mm OD, 22 mm Width, Open, 15°, Heavy preload.
