Fafnir2MM9117WI-DUHSuper Precision Angular Contact Ball Bearing — 85 x 130 x 22 mm, 15° Contact Angle, Phenolic Cage, Duplex Heavy Preload, Open

Condition: New
Condition Note: New Old Stock

Availability:

6 in stock

Fafnir 2MM9117WI-DUH super precision angular contact bearing pair, 85 x 130 x 22 mm, 15 degree contact angle, universally ground, heavy preload. 2 Pcs.

Same day shipment

List Price

$463.99

6 in stock

Prefer eBay? Buy this item on our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

6 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandFafnir
MPN2MM9117WI-DUH
Model2MM9117 WI DUH 7017C
Bearing TypeAngular Contact Ball Bearing, Open
ID85 mm
OD130 mm
Width22 mm

Technical Specifications

SeriesMM9100WI
PreloadHeavy
Base Number2MM9117WI
Industry Termsspindle bearing; super precision angular contact; machine tool bearing; duplex pair; ABEC 7 spindle bearing; precision ball bearing
Common MisspellingsFafner 2MM9117WI; Faffnir 2MM9117; 2MM911 7WI; 2MM-9171-WI-DUH; angualr contact bearing; Timkin Fafnir
Application TypesMachine tool spindles; grinding wheel heads; milling and boring spindles; precision rotary tables; high-speed gearbox input shafts
Bore Shaft Size85 mm (3.3465 in)
Mpn Variants2MM9117WIDUH; 2MM9117WI DUH; 2MM-9117-WI-DUH; 2MM 9117 WI DUH; 2MM9117WI-CR-DUH; 2MM9117WICRDUH; 2MM9117WI
Arrangement ConfigurationDuplex, universally ground (DU)
Precision ClassABEC 7 / P4
Rolling ElementsBall
Number Of Rows2 (one row per bearing in the supplied pair)
Bore TypeStraight
Harmonization Code8482.10.50.28
Contact Angle15°
Part Number2MM9117WI-DUH

Cross-References

Cross Reference 1SKF 7017 CD/P4ADGC - P4A class
Cross Reference 2FAG B7017-C-T-P4S-DUH - P4S class
Cross Reference 3NSK 7017CTYNDUHP4 - polyamide cage
Cross Reference 4Fafnir 2MM9117WI-DUL - light preload
Cross Reference 5Fafnir 2MM9117WI-DUM - medium preload
Seller Part Number: B-DC2#IBXMOZ

Product Description

What this part is:

Fafnir 2MM9117WI-DUH is a super-precision angular contact ball bearing, supplied as a universally ground duplex pair, 2 pieces, at heavy preload. Bore: 85 mm. Outside Diameter: 130 mm. Width: 22 mm per bearing. Single row per bearing, open. The ISO size is 7017. Fafnir is the Timken super-precision spindle bearing brand.

Decoding the designation:

2MM — 15° contact angle, P4 precision (ABEC 7).

9117 — Fafnir 9100 series, ISO 7017: ISO 70 dimension series, bore code 17 x 5 = 85 mm.

WI — low shoulder on both rings, the duplex form.

DU — duplex, universally ground.

H — heavy preload.

Specifications:

Bore Diameter: 85 mm (3.3465 in). Outside Diameter: 130 mm. Width: 22 mm per bearing. Contact Angle: 15°. Precision Class: ABEC 7 / P4. Preload: heavy. Arrangement: duplex, universally ground. Closure Type: open. Rolling Elements: balls. Number Of Rows: 1 per bearing, 2 in the pair. Unit Quantity: 2 Pcs.

Compatibility and replacement:

Cross-references: SKF 7017 CD/P4ADGC, 15° heavy preload, P4A class; FAG B7017-C-T-P4S-DUH, 15° heavy preload, P4S class; NSK 7017CTYNDUHP4, 15° heavy preload, polyamide cage. Same bearing at other preloads: Fafnir 2MM9117WI-DUL (light) and 2MM9117WI-DUM (medium).

Frequently asked questions:

What is the contact angle of the Fafnir 2MM9117WI-DUH?

15°, set by the 2MM prefix.

How many bearings are in this listing?

2 pieces, a universally ground duplex pair at heavy preload.

What size is the Fafnir 2MM9117WI-DUH?

85 mm bore, 130 mm outside diameter, 22 mm width per bearing.
