Availability:
Out of stock
Angular contact ball bearing pair, 25 mm bore, 52 mm OD, 15 mm wide, 30° contact angle, ABEC 5 / P5. Back-to-back DB matched set with polyamide cages.
List Price
$166.71
Out of stock
Out of stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Angular Contact Ball Bearing – 25 mm ID, 52 mm OD, 15 mm Width, Open, 40° Contact Angle, Polyamide Cage, Universally Matchable$33.14
Angular Contact Bearing - 25 mm ID, 52 mm OD, 15 mm Width, Open, 25° Contact Angle$67.10
Super-Precision Angular Contact Ball Bearing, 25 x 52 x 15 mm, 15 Degree Contact Angle, ABEC 7 / P4, Phenolic Cage, Universally Ground Duplex, Light Preload - 1 Pc (Half Pair)$70.24
Super Precision Angular Contact Ball Bearing, SINGLE Universally Ground, 25 x 52 x 15 mm, 25°, Phenolic Cage, P4 Light Preload$79.30| MFR / Brand | NTN |
|---|---|
| MPN | 7205T2DB/GNP5 |
| Model | 7205 T2 DB / GN P5 Duplex |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 25 mm |
| OD | 52 mm |
| Width | 15 mm |
| Base Number | 7205 |
|---|---|
| Total Width | 30 mm (DB pair) |
| Mpn Variants | 7205T2DB/GNP5, 7205T2DBGNP5, 7205 T2 DB GN P5, 7205T2DB-GNP5 |
| Precision Class | ABEC 5 / P5 |
| Series | 7200 |
| Rolling Elements | Ball |
| Cage Material | Polyamide |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 30° |
| Mounting Arrangement | Back-to-back (DB) |
| Cross Reference 1 | NSK 7205A (30°, DB, P5) |
|---|---|
| Cross Reference 2 | Koyo 7205 (30°, DB, P5) |
| Cross Reference 3 | Nachi 7205 (30°, DB, P5) |
NTN 7205T2DB/GNP5 is a matched pair of single-row angular contact ball bearings in the ISO 7205 size, ground for back-to-back mounting. Bore Diameter: 25 mm. Outside Diameter: 52 mm. Width: 15 mm per bearing. Total Width: 30 mm as a DB pair. Contact Angle: 30°. Cage Material: Polyamide. Precision Class: ABEC 5 / P5.
7205 — NTN single-row angular contact ball bearing, 72 series, 25 mm bore. No angle letter: 30° contact angle.
T2 — polyamide (nylon) cage.
DB — back-to-back matched pair. Two single-row bearings ground as a set. Not a double-row bearing.
GN — NTN standard preload code for the matched set.
P5 — ISO tolerance class 5, equivalent to ABEC 5.
The 30° contact angle carries combined radial and axial load. Back-to-back mounting takes axial load in both directions and gives the pair high tilting stiffness. ABEC 5 tolerances suit machine-tool and precision spindle duty.
Unit Quantity: 2 Pcs. One DB matched pair. Mounting Arrangement: Back-to-back (DB).
Same envelope and 30° angle: NSK 7205A, Koyo 7205 and Nachi 7205 in DB, P5 execution. SKF and FAG 7205 B executions are 40° and do not share the contact angle.
