Availability:
Out of stock
Precision angular contact ball bearing, 35 x 62 x 14 mm, 25° contact angle, NTN P42 class, Light preload (59 N), universal flush-ground. Dynamic 21,000 N.
List Price
$72.00
Out of stock
Out of stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Angular Contact Ball Bearing - 35 mm ID, 62 mm OD, 14 mm Width, 15° Contact Angle, Light Preload, ABEC 7 / P4, Phenolic Cage, Open.$51.83
Super Precision Angular Contact Ball Bearing - Straight Bore, 35 mm ID, 62 mm OD, 14 mm Width, Open, 15° Contact Angle, Universal Light Preload$75.13
Super Precision Angular Contact Ball Bearing - 35 mm ID, 62 mm OD, 14 mm Width, 25° Contact Angle, P4 / EP7, Light Preload, Open$88.77
Angular Contact Ball Bearing — 35 mm ID, 62 mm OD, 14 mm Width, 15° Contact Angle, ABEC 7, Light Preload$95.59| MFR / Brand | NTN |
|---|---|
| MPN | 7007UADG/GLP42 |
| Model | 7007 UADG GL P4 2 ABEC-7 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 35 mm |
| OD | 62 mm |
| Width | 14 mm |
| Material | Chrome Steel |
|---|---|
| Series | 7000 |
| Lubricant | Oil |
| Preload | Light |
| Mpn Variants | 7007UADG/GLP42, 7007UADGGLP42, 7007 UADG GL P42, 7007UADG-GLP42 |
| Precision Class | ABEC 7 / P4 (NTN P42) |
| Min Temp | -20 °C |
| Dynamic Load Rating | 21,000 N |
| Static Load Rating | 13,900 N |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 0.15 kg (0.33 lb) |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 20,900 rpm grease; 33,800 rpm oil |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 25° |
| Mounting Arrangement | Universal (flush-ground for DB, DF or DT) |
| Cross Reference 1 | SKF 7007 ACDGA/P4A |
|---|---|
| Cross Reference 2 | FAG B7007-E-T-P4S-UL |
| Cross Reference 3 | NSK 7007A5TYNSULP4 |
NTN 7007UADG/GLP42 is a high-precision single-row angular contact ball bearing for machine-tool spindles, flush-ground for universal matched mounting with a light preload. Bore Diameter: 35 mm. Outside Diameter: 62 mm. Overall Width: 14 mm. Contact Angle: 25°. It carries combined radial and single-direction axial load at high speed.
7007 — ISO 70 series angular contact ball bearing, bore code 07 = 35 mm.
AD — 25° contact angle.
G — flush-ground faces for universal matching in back-to-back, face-to-face or tandem sets.
GL — Light preload, 59 N when matched.
P42 — NTN precision class: ISO Class 4 (ABEC 7) dimensional tolerances with ISO Class 2 running accuracy.
Dynamic Load Rating: 21,000 N. Static Load Rating: 13,900 N. Limiting Speed: 20,900 rpm grease; 33,800 rpm oil. Preload: Light (59 N). Precision Class: ABEC 7 / P4 (NTN P42). Contact Angle: 25°. Rolling Elements: Ball. Closure Type: Open. Operating Temperature Range: -20 to 120 °C. Item Weight: 0.15 kg (0.33 lb). The 25° angle balances axial stiffness against speed capability.
Effective load centre a: 18.4 mm. Chamfer rs min: 1 mm. Chamfer r1s min: 0.6 mm. Inner ring shoulder d1: 44.2 mm. Inner ring shoulder d2: 42.2 mm. Outer ring shoulder D1: 52.8 mm. Outer ring shoulder D2: 56.9 mm. Abutment da min: 40.5 mm. Abutment Da max: 56.5 mm. Abutment Db max: 57.5 mm. Fillet ra max: 1 mm. Fillet r1a max: 0.6 mm.
Unit Quantity: 1 Pc. Single universal-matching bearing.
25°, P4-class, light-preload universal single bearings in the 35 x 62 x 14 mm envelope: SKF 7007 ACDGA/P4A, FAG B7007-E-T-P4S-UL, NSK 7007A5TYNSULP4.
