Angular Contact Ball Bearing – 110 mm Bore, 170 mm OD, 28 mm Width, 15° Contact Angle, Open$152.02
Double-Direction Axial Angular Contact Ball Bearing - 110 mm ID, 170 mm OD, 72 mm Width, 60° Contact Angle, Brass Cage, P5$350.49
Angular Contact Ball Bearing - 110 mm ID, 170 mm OD, 28 mm Width, Straight Bore, Open, 15 Degree, Light Section$358.51
Angular Contact Ball Bearing - Straight Bore, 110 mm ID, 170 mm OD, 28 mm Width, Open, 25° Contact Angle, Medium Preload$464.70| MFR / Brand | NSK |
|---|---|
| MPN | 110TAC20DNES7+LC7 |
| Model | 234422 / 110TAC20 D NES7+LC7 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 110 mm |
| OD | 170 mm |
| Width | 72 mm |
| Material | Bearing Steel |
|---|---|
| Series | TAC |
| Lubricant | Oil/Grease |
| Preload | Universal |
| Min Temp | -30 °C |
| Cage Type | Polyamide |
| Dynamic Load Rating | 72.5 kN |
| Static Load Rating | 230.0 kN |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 5.95 lbs |
| Cage Material | Polyamide |
| Number Of Rows | 2 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 60 ° |
| Mounting Arrangement | Universal |
| Limiting Speed | 2300 rpm |
| Cross Reference 1 | FAG 7602110-TVP |
|---|---|
| Cross Reference 2 | SKF BSD 110170/60 |
