Availability:
1 in stock
Single-row angular contact ball bearing, 110 mm bore x 170 mm OD x 28 mm wide, ISO 7022 envelope, open. 1 Pc.
List Price
$358.51
1 in stock
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
Also Available From:
| MFR / Brand | MRC |
|---|---|
| MPN | 122KR |
| Model | 122KR 7022C |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 110 mm |
| OD | 170 mm |
| Width | 28 mm |
| Material | Bearing Steel |
|---|---|
| Series | 100-KR |
| Condition | New |
| Lubricant | Oil/Grease |
| Base Number | 7022 |
| Industry Terms | Angular contact ball bearing, Marlin Rockwell bearing, precision ball bearing, spindle bearing |
| Common Misspellings | M.R.C., MCR, Marlin Rockwel, 122-K-R, 122 K R |
| Application Types | Machine tool spindles, pumps, gearboxes, combined radial and thrust load shafts |
| Bore Shaft Size | 110 mm (4.3307 in) |
| Mpn Variants | 122KR, 122-KR, 122 KR, 122KR7022C |
| Min Temp | -30 °C |
| Cage Type | Phenolic |
| Dynamic Load Rating | 100.0 kN |
| Static Load Rating | 102.0 kN |
| Precision Rating | ABEC 1 / P0 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 4.60 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15 ° |
| Mounting Arrangement | Single |
| Design Units | Metric |
| Part Number | 122KR |
| Cross Reference 1 | 7022 |
|---|---|
| Cross Reference 2 | 7022-C |
| Cross Reference 3 | 122-KR |
An MRC 122KR single-row angular contact ball bearing. Bore 110 mm, outside diameter 170 mm, width 28 mm, in the ISO 7022 envelope. Open on both faces.
1 — MRC angular contact ball bearing series
22 — bore code, 110 mm bore
ISO 7022 — the equivalent envelope, 110 x 170 x 28 mm
An angular contact ball bearing carries a combined radial and axial load, with the contact angle deciding how that split falls: a steeper angle takes more thrust and runs slower, a shallower angle the reverse. A single row takes thrust in one direction only, so a second bearing facing the other way carries thrust the other direction. The 28 mm width in a 110 mm bore puts this in the light 70-series section rather than the heavier 72 or 73 sections.
Bore: 110 mm (4.3307 in)
Outside diameter: 170 mm (6.6929 in)
Width: 28 mm (1.1024 in)
Number of rows: 1
Rolling elements: steel balls
Closure: open both faces
Bore type: straight
1 Pc.
The bearing mounts with an interference fit on the ring that rotates, seated square against a shoulder. Because a single row locates axially in one direction, the direction the bearing faces on assembly sets which way thrust is carried.
The ISO envelope equivalent is 7022, 110 x 170 x 28 mm. Envelope equivalence is not by itself interchange on an angular contact bearing: a 7022 at a different contact angle, preload or precision class is a related size. The MRC 122 number and its suffix identify the specific variant.
