FANUCSeries 160i-M Display and Operator Interface Module, Assembly 16IM-MCU24533-001R00

Product Description

What this part is

The display and operator interface module from a Fanuc Series 160i-M control, carrying the build number 16IM-MCU24533-001R00. It is the operator station assembly at the front of the machine: the part the operator looks at and presses. It is a fascia-level assembly, not a rack card, and not the CNC itself — the control unit, axis boards and servo amplifiers all live elsewhere in the cabinet.

Decoding the order code

16IM — the control family this module belongs to: Fanuc Series 16 / 160i, M for the machining-centre (milling) version.

MCU24533 — the machine-builder assembly number for the operator module as built into that control.

001 — assembly variant.

R00 — revision level of the assembly.

Published specifications

Type: display / operator interface module.

Platform: Fanuc Series 160i-M (Series 16i / 160i generation, machining centre control).

Assembly marking: 16IM-MCU24533-001R00.

Format: panel-mount operator station module.

What these specs mean in practice

Operator modules of this generation are built to the machine builder’s specification, which is why the marking on the unit is a builder assembly number rather than a plain Fanuc A02B order code. That makes the exact number the thing to match: cut-out size, connector positions and key mapping all follow the assembly, and a 160i module from a different builder or revision may physically fit and still not agree with the machine’s PMC.

Quantity and configuration

Sold as one module, as pictured.

What is not included

No CNC control unit, control boards, axis cards or memory. No separate MDI keyboard unit unless visible in the photographs. No cables, harnesses, video or signal leads, no connector kits. No inverter, backlight lamp or spare display parts. No mounting frame, escutcheon, gasket or hardware beyond what is shown. No battery, no software, no parameters, no documentation.

Interchange guidance

16IM-MCU24533-001R00, 16IM MCU24533 001R00 and MCU24533-001 refer to the same assembly. Other MCU-numbered operator modules from the Series 16i / 160i generation are related builds with different layouts and revisions — treat them as related, not as drop-in equivalents. Fanuc operator hardware is proprietary and there is no cross-brand substitute.
