Aventics1827231024Bourdon Tube Pressure Gauge — 40 mm Dial, 0-10 bar, G 1/8 Back Port, Class 1.6

Condition: New

Availability:

4 in stock

AVENTICS 1827231024 PG1-SNL Bourdon tube pressure gauge, 40 mm dial, 0 to 10 bar display, G 1/8 back port connection, class 1.6 to EN 837-1, for compressed air.

List Price

$33.62

4 in stock

Prefer eBay? Buy this item on our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

4 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandAventics
MPN1827231024
Model1 827 231 024

Technical Specifications

Air Pressure Range0-10 bar
Mpn Variants1827231024, 1 827 231 024, PG1-ROB-G018-SNL-D40P(0-10)
Min Temp-20 °C
SeriesPG1-SNL
Max Temp60 °C
TypePressure Gauge
Item Weight0.06 kg
Housing MaterialABS
Industry TermsBourdon tube pressure gauge; compressed air gauge; pneumatic pressure gauge; manometer; 40 mm gauge; 0-10 bar gauge
Common MisspellingsAventics 1 827 231 024; Aventis 1827231024; AVENTICS 1827231O24; Rexroth 1827231024
Application Typescompressed air systems; pneumatic equipment; air preparation units
Seller Part Number: AD1B5#FZBZKW

Product Description

What this part is:

AVENTICS 1827231024 is a Bourdon tube pressure gauge from the AVENTICS PG1-SNL series, with a back port G 1/8 connection and a 40 mm dial, for compressed air.

Decoding the designation:

PG1 — AVENTICS pressure gauge series.

ROB — Bourdon tube gauge.

G018 — G 1/8 compressed air connection.

D40 — 40 mm nominal diameter.

(0-10) — 0 to 10 bar display range.

Specifications:

Pressure Gauge Version: Bourdon tube pressure gauge, back port. Standardization: EN 837-1. Class: 1.6. Certification: Suitable for ATEX. Compressed Air Connection: G 1/8. Nominal Diameter: 40 mm. Scale Value: 0.5. Display Range: 0 to 10 bar. Range of Application: 0 to 8 bar. Working Pressure: 0 to 10 bar. Ambient Temperature: -20 °C to 60 °C. Medium: Compressed air. Main Scale: bar, green. Secondary Scale: psi, white. Background Color: Black. Pointer Color: White. Housing Material: Acrylonitrile butadiene styrene (ABS). Viewing Window Material: Polystyrene. Weight: 0.06 kg.

Dimensions and mounting:

Dial Size: 40 mm. Connection: G 1/8, back (rear) port.

Compatibility and replacement:

Part number formats: 1827231024, 1 827 231 024, AVENTICS-1827231024. Product code: PG1-ROB-G018-SNL-D40P(0-10). Formerly sold under the Rexroth Pneumatics name.

CAD model and data sheet: available from Emerson AVENTICS (discreteautomation.emerson.com).

Frequently asked questions:

What pressure range does the AVENTICS 1827231024 read?

The dial displays 0 to 10 bar with a secondary psi scale; the range of application is 0 to 8 bar.

What is the connection thread?

G 1/8 on a back port.

What accuracy class is the gauge?

Class 1.6 to EN 837-1.
