Availability:
Out of stock
List Price
$62.74
Out of stock
Out of stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Double-Row Spherical Roller Bearing — 85 mm ID, 150 mm OD, 36 mm Width, Tapered Bore 1:12, C3 Clearance, W33 Groove$126.21
Spherical Roller Bearing - 85 mm ID, 150 mm OD, 36 mm Width, 1:12 Tapered Bore, Brass Cage, C3, W33 Lube Groove$117.62
Spherical Roller Bearing - Straight Bore, 85 mm ID, 150 mm OD, 36 mm Width, W33 Lubrication Groove$46.69
Double-Row Spherical Roller Bearing, 85 x 150 x 36 mm, 1:12 Tapered Bore, ULTAGE High-Capacity Design, W33 Lubrication, C4 Clearance, 200 C Rated$68.65| MFR / Brand | NSK |
|---|---|
| MPN | 22217CDKE4C3S11 |
| Model | 22217 CD K W33/E4 C3 S11 / 22217CCK 22217CKJ 22217CCKJ 22217CKJ |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 85 mm |
| OD | 150 mm |
| Width | 36 mm |
| Series | 22200 |
|---|---|
| Bore | Taper Bore |
| Material | Bearing Steel |
| Min Temp | -30 °C |
| Cage Type | Stamped |
| Dynamic Load Rating | 310 kN / 69700 lbf |
| Static Load Rating | 325 kN / 73100 lbf |
| Precision Rating | ABEC 1 / P0 |
| Rolling Elements | Spherical Rollers |
| Max Temp | 200 °C |
| Item Weight | 5.51 lbs |
| Cage Material | Steel |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Snap Ring Included | Without Snap Ring |
| Relubrication Feature | Yes |
| Harmonization Code | 8482.30.00 |
| Internal Clearance | C3 |
| Limiting Speed | 3400 rpm |
| Maximum Permissible Misalignment | 2° |
| Cross Reference 1 | SKF 22217 EK/C3 |
|---|---|
| Cross Reference 2 | FAG 22217-E1-K-C3 |
| Cross Reference 3 | Timken 22217K-C3 |
Spherical Roller Bearing – Tapered Bore, 85 mm ID, 150 mm OD, 36 mm Width, Open, C3 Internal clearance
$64.17
13 in stock
$67.31
10 in stock
$43.38
64 in stock
$61.18
97 in stock
