Spherical roller bearing, 50 x 90 x 23 mm, tapered bore, C3, Cr 124,000 N. NSK 22210EAKE4C3 with E4 groove, pressed steel cage, mounts on an H310 sleeve.
List Price
$46.64
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NSK |
|---|---|
| MPN | 22210EAKE4C3 |
| Model | 22210-EA-KE4-C3 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 50 mm |
| OD | 90 mm |
| Width | 23mm |
| Series | 222 |
|---|---|
| Material | Bearing Steel |
| Dynamic Load Rating | 124,000 N |
| Static Load Rating | 119,000 N |
| Rolling Elements | Spherical Roller |
| Item Weight | 0.61 kg (1.34 lb) |
| Cage Material | Pressed steel |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Snap Ring Included | No |
| Limiting Speed | 5,600 rpm grease; 7,100 rpm oil |
| Harmonization Code | 8482.30.00 |
| Internal Clearance | C3 |
| Overall Width | 23 mm |
| Mpn Variants | 22210EAKE4C3, 22210-EA-KE4-C3, 22210EAKE4, 22210 C K W33 C3, 22210CKJ, 22210CC |
| Compatible With Replaces | Adapter sleeve H310 |
| Precision Class | ISO Normal |
| Lubricant | grease or oil |
| Industry Terms | spherical roller bearing; self-aligning roller bearing; tapered bore spherical bearing; 50x90x23 bearing; W33 bearing |
| Common Misspellings | NSK 22210 EAKE4 C3, NSK 22210EAK E4 C3, NKS 22210EAKE4C3, NSK 22210-EAKE4-C3 |
| Application Types | Gearboxes; pumps; conveyors; crushers; industrial machinery |
| Cross Reference 1 | SKF 22210 EK/C3 (no W33 groove) |
|---|---|
| Cross Reference 2 | FAG 22210-E1-K-C3 (no W33 groove) |
| Cross Reference 3 | Timken 22210KEJW33C3 |
NSK 22210EAKE4C3 is a high-capacity double-row spherical roller bearing with a 1:12 tapered bore. Unit Quantity: 1 Pc.
22210 — ISO 222 series spherical roller bearing, 50 mm bore, 90 mm OD, 23 mm width.
EA — NSK high-capacity design with pressed steel cages.
K — 1:12 tapered bore.
E4 — lubrication groove and three holes in the outer ring, equivalent to W33.
C3 — radial internal clearance greater than normal.
Bore Diameter: 50 mm. Outside Diameter: 90 mm. Overall Width: 23 mm. Dynamic Load Rating: 124,000 N. Static Load Rating: 119,000 N. Limiting Speed: 5,600 rpm grease; 7,100 rpm oil. Item Weight: 0.61 kg (1.34 lb). Cage Material: Pressed steel. Internal Clearance: C3. Precision Class: ISO Normal. Lubricant: grease or oil. Rolling Elements: Spherical Roller.
Bore Type: Tapered 1:12. Mounts on an H310 adapter sleeve with KM10 locknut and MB10 washer.
Cross-References: SKF 22210 EK/C3 (no W33 groove), FAG 22210-E1-K-C3 (no W33 groove), Timken 22210KEJW33C3. Also written 22210-EA-KE4-C3 and 22210EAKE4.
124,000 N.
H310.
5,600 rpm on grease and 7,100 rpm on oil-bath lubrication.
