Double-row spherical roller bearing, 55 x 100 x 25 mm, 1:12 tapered bore, W33 lubrication groove, open, CN clearance, chrome steel. GTIN 4026677804969.
List Price
$50.99
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 22211-E1-K |
| GTIN | 4026677804969 |
| Model | 22211 E1 K W33 |
| Bearing Type | Spherical Roller Bearing |
| ID | 55 mm |
| OD | 100 mm |
| Width | 25 mm |
| Lubricant | Grease or oil |
|---|---|
| Series | 222 |
| Material | Chrome steel |
| Base Number | 22211 |
| Total Width | 25 mm |
| Overall Width | 25 mm |
| Bore Shaft Size | 55 mm |
| Mpn Variants | 22211E1K, 22211-E1-K, 22211 E1 K W33, 22211EK, 22211-E1-K-W33 |
| Additional Attributes | Adapter sleeve H311; locknut KM11; lockwasher MB11 |
| Rolling Elements | Spherical rollers |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Design Units | Metric |
| Bearing Material | Chrome steel |
| Part Number | 22211-E1-K-W33 |
| Industry Terms | spherical roller bearing; tapered bore spherical; self-aligning roller bearing; W33 groove bearing; 22211 K bearing |
| Common Misspellings | FAG 22211 E1 K; FAG 22211E1K; FGA 22211-E1-K; FAG 22211 EK W33; FAG 22211-E1K |
| Application Types | Gearboxes; pumps and fans; conveyors; industrial machinery on adapter-sleeve mounted shafts |
| Cross Reference 1 | SKF 22211 EK |
|---|---|
| Cross Reference 2 | NSK 22211EAKE4 |
| Cross Reference 3 | Timken 22211KEJW33 |
FAG 22211-E1-K-W33 double-row spherical roller bearing, 55 x 100 x 25 mm, with a 1:12 tapered bore, reinforced E1 design and a W33 lubrication groove with three radial holes in the outer ring. Open on both faces. Unit Quantity: 1 Pc. GTIN: 4026677804969.
22211 — FAG number for the 222 dimension series, 55 x 100 x 25 mm.
E1 — reinforced execution with a larger roller complement than the original 222 design.
K — tapered bore, 1:12 taper.
W33 — annular groove around the outer ring outside diameter with three radial feed holes.
Bore Diameter: 55 mm.
Outside Diameter: 100 mm.
Overall Width: 25 mm.
Bore Type: Tapered 1:12.
Rolling Elements: Spherical roller.
Number Of Rows: 2.
Series: 222.
Base Number: 22211.
Internal Clearance: CN.
Closure Type: Open.
Lubricant: grease or oil, fed through the W33 groove and holes.
Bearing Material: Chrome steel.
Design Units: Metric.
GTIN: 4026677804969.
The 1:12 tapered bore seats on an adapter sleeve. Adapter Sleeve: H311, tapered outside diameter 55 mm, shaft seat 50 mm. Locknut: KM11. Lockwasher: MB11.
Crosses with a 1:12 tapered bore at 55 x 100 x 25 mm: SKF 22211 EK, NSK 22211EAKE4, Timken 22211KEJW33. Also written 22211E1K, 22211-E1-K, 22211 E1 K W33, 22211EK.
The H311 sleeve, with a KM11 locknut and MB11 lockwasher.
1:12, designated by the K in the part number.
An annular groove around the outer ring outside diameter with three radial holes for lubricant feed.
