Double-row spherical roller bearing, 55 x 100 x 25 mm, straight bore, W33 lubrication groove and three holes, steel cage, CN clearance, open.
List Price
$51.53
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Torrington |
|---|---|
| MPN | 22211CJW33 |
| Model | 22211 CJ W33 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 55 mm |
| OD | 100 mm (3.937 in) |
| Width | 25 mm (0.9843 in) |
| Material | Chrome Steel |
|---|---|
| Series | 22200 |
| Lubricant | Grease or oil |
| Base Number | 22211 |
| Industry Terms | Double row spherical roller bearing; self-aligning roller bearing; W33 spherical roller; 222 series spherical roller |
| Bore Shaft Size | 55 mm |
| Mpn Variants | 22211-CJ-W33; 22211 CJ W33; 22211CJ; 22211W33 |
| Compatible With Replaces | Timken's current designation for this bearing is 22211EJW33. Related part: 22211K, same envelope with a 1:12 tapered bore, mounts on an H311 adapter sleeve |
| Rolling Elements | Spherical Rollers |
| Number Of Rows | 2 |
| Bore Type | Straight (cylindrical) |
| Harmonization Code | 8482.30.00.80 |
| Part Number | 22211CJW33 |
| Maximum Permissible Misalignment | 1.5° |
| Cross Reference 1 | Timken 22211EJW33 - current designation |
|---|---|
| Cross Reference 2 | SKF 22211 E - E design, higher ratings |
| Cross Reference 3 | FAG 22211-E1-XL - reinforced design |
| Cross Reference 4 | NSK 22211EAE4 |
Torrington 22211CJW33 double-row spherical roller bearing, 222 series, 55 mm bore x 100 mm outside diameter x 25 mm width, straight bore, open. Unit Quantity: 1 Pc.
222 — double-row spherical roller series.
11 — bore code, 55 mm.
CJ — two-piece steel window cage. Timken’s current designation for this bearing is 22211EJW33.
W33 — annular lubrication groove in the outer ring outside diameter with three radial holes through to the rollers.
Bore Diameter: 55 mm. Outside Diameter: 100 mm (3.937 in). Overall Width: 25 mm (0.9843 in). Bore Type: Straight (cylindrical). Number Of Rows: 2. Rolling Elements: Spherical Rollers. Closure Type: Open. Cage Material: Steel. Cage Type: Two-piece window. Internal Clearance: CN. Maximum Permissible Misalignment: 1.5°. Lubricant: grease or oil. Material: Chrome Steel. Series: 222. Base Number: 22211. Axial load factors: e 0.23, Y 2.95 where the axial load is at or below e times the radial load and 4.40 above it, Y0 2.89. Geometry factor Cg: 0.052. Unit Quantity: 1 Pc.
Maximum Shaft Fillet Radius: 1.5 mm (0.060 in). Shaft Backing Shoulder Diameter: 66.0 mm (2.600 in). Housing Backing Shoulder Diameter: 91.0 mm (3.600 in).
Cross-Reference 1: Timken 22211EJW33, current designation. Cross-Reference 2: SKF 22211 E, E design with higher ratings. Cross-Reference 3: FAG 22211-E1-XL, reinforced design. Cross-Reference 4: NSK 22211EAE4. Related part: 22211K, 1:12 tapered bore, mounts on an H311 adapter sleeve. Searchable forms: 22211-CJ-W33, 22211 CJ W33, 22211CJ, 22211W33.
Bore Diameter: 55 mm. Outside Diameter: 100 mm. Overall Width: 25 mm.
W33 is an annular groove in the outer ring outside diameter with three radial holes. Lubricant: grease or oil.
Maximum Permissible Misalignment: 1.5°.
