Availability:
8 in stock
Self-aligning ball bearing, 45 x 85 x 23 mm, tapered 1:12 bore, C3 clearance, polyamide cage. Dynamic load rating 32,500 N. Mounts on an H 309 adapter sleeve.
List Price
$41.20
8 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| Model | 2209EK TN9 C3 |
| Bearing Type | Self Aligning Ball Bearing, Open |
| ID | 45 mm |
| OD | 85 mm |
| Width | 23 mm |
| Material | Bearing steel |
|---|---|
| Series | 2200 |
| Mpn Variants | 2209 EKTN9/C3, 2209-EKTN9-C3, 2209EKTN9C3, 2209 E K TN9 C3, 2209K C3 |
| Compatible With Replaces | SKF H 309 adapter sleeve |
| Precision Class | Normal |
| Dynamic Load Rating | 32,500 N |
| Static Load Rating | 10,600 N |
| Rolling Elements | Ball |
| Item Weight | 0.528 kg (1.16 lb) |
| Cage Material | Glass fibre reinforced polyamide |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Snap Ring Included | No |
| Limiting Speed | 10,000 rpm |
| Internal Clearance | C3 |
| Harmonization Code | 8482.10.50 |
| Bearing Material | Bearing steel |
| Maximum Permissible Misalignment | 1.5° |
| Cross Reference 1 | FAG 2209-K-TVH-C3 – tapered 1:12, C3; cage may differ |
|---|---|
| Cross Reference 2 | NSK 2209KC3 – tapered 1:12, C3; cage may differ |
| Cross Reference 3 | NTN 2209SKC3 – tapered 1:12, C3; cage may differ |
| Cross Reference 4 | Koyo 2209KC3 – tapered 1:12, C3; cage may differ |
A double-row self-aligning ball bearing with a tapered bore, SKF 2209 EKTN9/C3. Bore Diameter: 45 mm. Outside Diameter: 85 mm. Overall Width: 23 mm. Bore Type: Tapered 1:12. Number Of Rows: 2. Rolling Elements: Ball. Closure Type: Open. Bearing Material: Bearing steel.
2209 — self-aligning ball bearing, dimension series 22, bore code 09, giving the 45 x 85 x 23 mm envelope.
E — SKF reinforced internal design.
K — tapered bore, taper 1:12.
TN9 — glass fibre reinforced polyamide 66 cage.
C3 — radial internal clearance greater than normal.
Dynamic Load Rating: 32,500 N. Static Load Rating: 10,600 N. Reference Speed: 15,000 rpm. Limiting Speed: 10,000 rpm. Maximum Permissible Misalignment: 1.5°. The sphered outer raceway lets the inner ring and ball set tilt relative to the housing, accommodating shaft deflection and mounting misalignment. Internal Clearance: C3. Precision Class: Normal. Cage Material: Glass fibre reinforced polyamide.
Bore Type: Tapered 1:12. Mounts on an SKF H 309 adapter sleeve with KM 9 lock nut and MB 9 lock washer, or on a withdrawal sleeve. Item Weight: 0.528 kg (1.16 lb).
Unit Quantity: 1 Pc.
Tapered 1:12 bore, C3 clearance, 45 x 85 x 23 mm: FAG 2209-K-TVH-C3, NSK 2209KC3, NTN 2209SKC3 and Koyo 2209KC3. Cage design can differ between makers.
