Split pillow block housing only, four-bolt, cast iron, 3.75 in centre height, 9.88-11.00 in bolt centres. Dodge USAF 500 series CH4S-517-USAF, 039509.
List Price
$285.38
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Dodge |
|---|---|
| MPN | CH4S-517-USAF |
| Model | CH4S 517 USAF / 039509 |
| Type | Pillow Block Housing |
|---|---|
| Bolt Center To Center | 9.88-11.00 in |
| Number Of Bolt Holes | 4 |
| Bolt Center To Center Length | 9.88-11.00 in |
| Number Of Bolt Holes For Fasteners | 4 |
| Centre Height Pillow Block | 3.7500 in |
| Centre Height | 3.7500 in |
| Housing Style | Four-Bolt Pillow Block, Split |
| Relubrication | Yes, greasable |
| Mpn Variants | CH4S-517-USAF, CH4S517USAF, CH4S 517 USAF, 039509 |
| Additional Attributes | Bolt width 2.13 in between bolt rows; Dodge part number 039509; Dodge manual MN3010 (Adapter Mounted USAF 500/600 Series); greasable |
| Material | Cast Iron |
| Series | USAF 500 |
| Bearing Type | Split Pillow Block Housing |
| Item Weight | 17.68 kg (38.97 lb) |
| Harmonization Code | 8483.30.80.20 |
| Housing Material | Cast Iron |
Dodge CH4S-517-USAF split pillow block housing for the USAF adapter-mounted spherical roller bearing line, Dodge part number 039509. Housing only: four-bolt pillow block, split, cast iron. Unit Quantity: 1 Pc.
USAF — Dodge USAF adapter-mounted spherical roller pillow block line, 500 series.
517 — Dodge USAF housing size.
Housing Style: Four-Bolt Pillow Block, Split. Housing Material: Cast iron. Bearing Component: Housing only. Relubrication: Greasable. Series: USAF 500. Item Weight: 17.68 kg (38.97 lb). Dodge Part Number: 039509.
Centre Height: 3.7500 in, base to bore centreline. Bolt Center To Center: 9.88 to 11.00 in, slotted. Bolt Width: 2.13 in between bolt rows. Bolt Diameter: 0.625 in. Number Of Bolt Holes For Fasteners: 4.
Dodge category: Spherical Roller, SAF, Split Housings. Dodge manual: MN3010, Adapter Mounted USAF 500/600 Series.
A four-bolt split pillow block housing in cast iron, greasable, sold as housing only.
Bolt center to center 9.88 to 11.00 in (slotted), bolt width 2.13 in, centre height 3.7500 in.
Part number 039509; weight 17.68 kg (38.97 lb).
