Deep Groove Ball Bearing — 100 mm Bore, 215 mm OD, 47 mm Width, Steel Shields Both Sides$302.14| MFR / Brand | NTN |
|---|---|
| MPN | 6320LLUC3 |
| Model | 6320RS C3 |
| Bearing Type | Ball Bearing, Double Rubber Seal |
| ID | 100 mm |
| OD | 215 mm |
| Width | 47 mm |
| Material | Bearing Steel |
|---|---|
| Series | 6300 |
| Lubricant | Oil/Grease |
| Min Temp | -30 °C |
| Cage Type | Stamped Steel |
| Dynamic Load Rating | 173.0 kN |
| Static Load Rating | 141.0 kN |
| Precision Rating | ABEC 1 / P0 |
| Rolling Elements | Ball |
| Max Temp | 110 °C |
| Item Weight | 15.40 lbs |
| Cage Material | Steel |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Internal Clearance | C3 |
| Limiting Speed | 2800 rpm |
| Cross Reference 1 | SKF 6320-2RS1/C3 |
|---|---|
| Cross Reference 2 | FAG 6320-2RSR-C3 |
