Sealed deep groove ball bearing, 60 x 110 x 22 mm, contact rubber seals both sides, C3 clearance, 58,000 N dynamic rating. NTN 6212LLUC3, 3,800 rpm.
List Price
$38.23
3 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NTN |
|---|---|
| MPN | 6212LLUC3 |
| Model | 6212LLUC3 / 2AS |
| Bearing Type | Deep Groove Ball Bearing, Contact seals both sides |
| ID | 60 mm |
| OD | 110 mm |
| Width | 22 mm |
| Material | High Carbon Chrome Steel |
|---|---|
| Series | 6200 |
| Mpn Variants | 6212LLUC3; 6212LLUC3/2AS; 6212LLU C3; 6212LU |
| Precision Class | ABEC 1 / P0 |
| Min Temp | -40 °C |
| Cage Type | Pressed |
| Dynamic Load Rating | 58,000 N |
| Static Load Rating | 36,000 N |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 0.78 kg (1.72 lb) |
| Cage Material | Pressed steel |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 3,800 rpm grease |
| Internal Clearance | C3 |
| Lubricant | Shell Alvania No. 2 grease |
| Harmonization Code | 8482.10.50.68 |
| Bearing Material | High carbon chrome steel |
| Closure Type | Contact seals both sides |
| Industry Terms | Sealed deep groove ball bearing; 6212 rubber sealed bearing; 60x110x22 bearing; 6212-2RS equivalent size |
| Common Misspellings | 6212LLU C3; 6212 LLUC3; 6212LUUC3; 6212LLCU3 |
| Application Types | Electric motors; pumps; gearboxes; general industrial machinery |
| Cross Reference 1 | SKF 6212-2RS1/C3 (related, contact seals both sides) |
|---|---|
| Cross Reference 2 | FAG 6212-2RSR-C3 (related, contact seals both sides) |
| Cross Reference 3 | NSK 6212DDUC3 (related, contact seals both sides) |
| Cross Reference 4 | Koyo 6212-2RSC3 (related, contact seals both sides) |
NTN 6212LLUC3 is a single-row deep groove ball bearing in the ISO 6212 size, sealed both sides with contact rubber seals. Bore Diameter: 60 mm. Outside Diameter: 110 mm. Overall Width: 22 mm. Seal Type: Contact seals both sides. Seal Material: Nitrile rubber. Internal Clearance: C3. Precision Class: ABEC 1 / P0. Rolling Elements: Ball. Number Of Rows: 1.
62 — NTN 02 dimension series, the light-series deep groove section.
12 — bore code: 12 x 5 = 60 mm bore.
LLU — contact rubber seals on both sides.
C3 — radial internal clearance greater than normal.
2AS — NTN grease code for Shell Alvania No. 2, carried on the carton.
Bearing Type: Deep Groove Ball Bearing. Bore Diameter: 60 mm. Outside Diameter: 110 mm. Overall Width: 22 mm. Dynamic Load Rating: 58,000 N. Static Load Rating: 36,000 N. Limiting Speed: 3,800 rpm grease. Lubricant: Shell Alvania No. 2 grease. Cage Material: Pressed steel. Cage Type: Pressed. Bearing Material: High carbon chrome steel. Item Weight: 0.78 kg (1.72 lb). Operating Temperature: -40 to 120 °C. Series: 6200. Snap Ring Included: No. Harmonization Code: 8482.10.50.68. Unit Quantity: 1 Pc.
Fillet Radius r min: 1.5 mm. Shaft Abutment da max: 75 mm. Housing Abutment Da max: 102 mm. Max Fillet ras: 1.5 mm.
Cross-references with a 60 x 110 x 22 mm size, contact seals both sides and C3 clearance: SKF 6212-2RS1/C3, NSK 6212DDUC3, FAG 6212-2RSR-C3, Koyo 6212-2RSC3. Designation variants: 6212LLUC3, 6212LLUC3/2AS, 6212LLU C3, 6212LU.
Bore Diameter: 60 mm. Outside Diameter: 110 mm. Overall Width: 22 mm.
Seal Type: Contact seals both sides. Seal Material: Nitrile rubber.
Dynamic Load Rating: 58,000 N. Static Load Rating: 36,000 N. Limiting Speed: 3,800 rpm grease.
