Availability:
34 in stock
Open thin-section radial contact ball bearing, 70 x 86 x 8 mm, square 8 x 8 mm section, Kaydon Class 1 (ABEC 1F), AISI 52100 steel, snap-over separator.
List Price
$167.49
34 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Kaydon |
|---|---|
| MPN | K07008CT0 |
| Model | K 07008 C T0 |
| Bearing Type | Deep Groove Ball Bearing |
| ID | 70 mm |
| OD | 86 mm |
| Width | 8 mm |
| Material | Steel |
|---|---|
| Base Number | K07008 |
| Industry Terms | Thin section bearing, Reali-Slim bearing, slim line bearing, radial contact bearing, Conrad bearing, square section bearing, large through bore bearing, gimbal bearing |
| Common Misspellings | K07008CTO, K07008 CT-0, KO7008CT0, K7008CT0, Kaydon K07008C10 |
| Application Types | Robot and gimbal joints, rotary tables and indexers, medical imaging, semiconductor handling, optical and camera mounts, hollow-shaft drives |
| Total Width | 8 mm |
| Bore Shaft Size | 70 mm |
| Mpn Variants | K07008CT0, K07008-CT0, K07008 CT0, K07008CT0-10111, K-07008-CT0, K07008 |
| Precision Class | Kaydon Class 1 (ABEC 1F) |
| Dynamic Load Rating C1 | 4,089 N radial, per bearing |
| Additional Attributes | Land diameter L1: 75.9 mm. Land diameter L2: 80.1 mm. Maximum shaft or housing fillet radius the bearing corners clear (F): 0.8 mm. Cross-section: 8 x 8 mm square. Ball diameter: 5/32 in. |
| Cage Type | Formed-ring snap-over separator |
| Dynamic Load Rating | 4,089 N radial (Kaydon); 7,041 N radial (ISO 281:1990) |
| Static Load Rating | 7,433 N radial (non-brinell limit) |
| Precision Rating | Kaydon Class 1 (ABEC 1F) |
| Rolling Elements | Balls, 5/32 in |
| Item Weight | 0.10 kg (0.22 lb) |
| Number Of Rows | 1 |
| Design Units | Metric |
| Bearing Material | AISI 52100 bearing steel |
| Series | Reali-Slim MM metric, 8 mm square section |
| Part Number | K07008CT0 |
| Closure Type | Open |
Kaydon K07008CT0 Reali-Slim thin-section radial contact (Conrad deep groove) ball bearing, single row, open. Bore 70 mm, outside diameter 86 mm, width 8 mm, square 8 x 8 mm cross section. Carries radial load plus thrust in either direction.
K — AISI 52100 bearing steel races and balls, open.
070 — 70 mm bore.
08 — 8 mm square cross section.
C — radial contact (Conrad deep groove) type.
T — formed-ring snap-over separator.
0 — Kaydon Precision Class 1 (ABEC 1F), standard internal fit for the size.
-10111 — Kaydon build reference carried on the carton.
Bore Diameter: 70 mm. Outside Diameter: 86 mm. Width: 8 mm. Cross Section: 8 x 8 mm, square. Number Of Rows: 1. Closure Type: Open. Rolling Elements: Balls, 5/32 in. Cage Type: Formed-ring snap-over separator. Precision Class: Kaydon Class 1 (ABEC 1F). Internal Fit: Standard for the size. Bearing Material: AISI 52100 bearing steel. Dynamic Load Rating: 4,089 N radial (Kaydon, 1 million revolutions L10), 7,041 N radial (ISO 281:1990 basis). Static Load Rating: 7,433 N radial (non-brinell limit, rigid support). Load ratings are per bearing. Item Weight: 0.10 kg (0.22 lb). Unit Quantity: 1 Pc.
Land Diameter L1: 75.9 mm. Land Diameter L2: 80.1 mm. Maximum shaft or housing fillet radius the bearing corners clear (F): 0.8 mm. Bearing corners are chamfered.
MPN variants: K07008CT0, K07008-CT0, K07008 CT0, K07008CT0-10111, K-07008-CT0, K07008.
Bore 70 mm, outside diameter 86 mm, width 8 mm, with a square 8 x 8 mm cross section.
Radial contact (Conrad deep groove), single row, open. The C in the designation is the Kaydon type letter for radial contact.
Dynamic radial 4,089 N (Kaydon L10 basis) or 7,041 N (ISO 281:1990 basis), static radial 7,433 N, per bearing.
