Availability:
6 in stock
Spindle deep groove ball bearing, 55 x 90 x 18 mm, open, straight bore. ABEC 3 precision, CN clearance, single row of chrome steel balls.
List Price
$31.24
6 in stock
6 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
Also Available From:
| MFR / Brand | Fafnir |
|---|---|
| Model | M 9111 K / 6011 P6 |
| Bearing Type | Deep Groove Ball Bearing, Open |
| ID | 55 mm |
| OD | 90 mm |
| Width | 18 mm |
| Material | Steel |
|---|---|
| Series | 9100K |
| Condition | New – Open box |
| Lubricant | Oil Preservative |
| Base Number | 9111K |
| Industry Terms | Spindle deep groove ball bearing, precision radial ball bearing, machine tool spindle bearing |
| Common Misspellings | M9111-K, M911 1K, MM9111-K, M91111K, 9111M |
| Condition Note | Made In USA |
| Overall Width | 18 mm |
| Mpn Variants | M9111K, M-9111-K, M 9111 K, 9111K, MM9111K, 6011 |
| Precision Class | ABEC 3 / P6 |
| Dynamic Load Rating C1 | 31,400 N |
| Additional Attributes | C1 ISO dynamic radial rating per row: 28,500 N; max shaft fillet radius 1 mm; shaft backing shoulder diameter 62.2 mm; housing backing shoulder diameter 83.3 mm |
| Dynamic Load Rating | 31,400 N |
| Static Load Rating | 21,400 N |
| Precision Rating | ABEC 3 / P6 |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Internal Clearance | CN |
| Harmonization Code | 8482.10.50 |
| Design Units | Metric |
| Bearing Material | Chrome steel |
| Part Number | M9111K |
| Cross Reference 1 | Timken MM9111K (same size, P4S super-precision execution) |
|---|---|
| Cross Reference 2 | Fafnir 9111K (same spindle deep groove size) |
| Cross Reference 3 | SKF 6011 (related, standard-class Conrad type, same envelope) |
| Cross Reference 4 | FAG 6011 (related, standard-class Conrad type, same envelope) |
| Cross Reference 5 | NSK 6011 (related, standard-class Conrad type, same envelope) |
| Cross Reference 6 | NTN 6011 (related, standard-class Conrad type, same envelope) |
| Cross Reference 7 | Koyo 6011 (related, standard-class Conrad type, same envelope) |
| Cross Reference 8 | MRC 111S (related, standard-class Conrad type, same envelope) |
| Cross Reference 9 | Nachi 6011 (related, standard-class Conrad type, same envelope) |
What this part is: Fafnir M9111K single-row spindle deep groove ball bearing, 9100K series, made in the USA. Bore Diameter: 55 mm. Outside Diameter: 90 mm. Overall Width: 18 mm. Bore Type: Straight. Closure Type: Open. Rolling Elements: Ball. Number Of Rows: 1. Bearing Material: Chrome steel. Internal Clearance: CN. Precision Class: ABEC 3 / P6. Series: 9100K. Base Number: 9111K. Decoding the designation: 9111 — 9100 light series, bore code 11, giving a 55 mm bore on the 90 mm outside diameter of the 6011 envelope. K — spindle deep groove execution: a Conrad-type deep groove raceway built to spindle tolerances, so it carries no contact angle. What these specs mean in practice: Dynamic Load Rating: 31,400 N at one million revolutions, and 28,500 N on the ISO basis. Static Load Rating: 21,400 N. Precision Class: ABEC 3 / P6, a tighter running and dimensional tolerance than a standard commercial deep groove bearing. Internal Clearance: CN, the standard clearance group. The 9100 light series puts a thinner section on a given bore, which keeps the bearing compact where the housing bore is limited, and the deep groove raceway still takes axial load from either direction alongside the radial load. Mounting data: Maximum shaft fillet radius cleared by the bearing corner: 1 mm. Shaft backing shoulder diameter: 62.2 mm. Housing backing shoulder diameter: 83.3 mm. Outer ring “to clear” radius: 1 mm. Lubricant: grease or oil. Quantity and configuration: Unit Quantity: 1 Pc. Single bearing, open on both faces. Interchange guidance: The envelope is the standard 6011 boundary at 55 x 90 x 18 mm, so a standard-class 6011 from SKF, FAG, NSK, NTN, Koyo, MRC or Nachi fits the same seat. Those are commercial Conrad-type bearings at normal tolerance; this piece is the spindle execution at ABEC 3, and the Timken MM9111K is the same size at P4S. Searchable forms of the number: M9111K, M-9111-K, M 9111 K, 9111K, MM9111K and 6011.
Original price was: $79.70.$59.78Current price is: $59.78.
3 in stock
Original price was: $98.88.$74.16Current price is: $74.16.
16 in stock
Original price was: $98.88.$74.16Current price is: $74.16.
16 in stock
