Availability:
Out of stock
Super-precision angular contact ball bearing, 20 x 47 x 14 mm, 25° contact angle, tolerance class P4A. Universally matchable, extra light preload (GA).
List Price
$152.81
Out of stock
Out of stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Super-Precision Angular Contact Ball Bearing - 20 mm Bore x 47 mm OD x 14 mm Width, Open, 25 Degree, Extra Light Preload$86.90
Super-Precision Angular Contact Ball Bearing, Matched Pair - Straight Bore, 20 mm ID, 47 mm OD, 14 mm Width, Open, 25° Contact Angle, Extra Light Preload$173.80
Angular Contact Ball Bearing Matched Pair - 20 mm Bore, 47 mm OD, 14 mm Width, 25° Contact Angle, Phenolic Cage, Light Preload, P3 Precision$107.36
Super-Precision Angular Contact Ball Bearing - 20 mm Bore x 47 mm OD x 14 mm Width, Open, 15 Degree, Extra Light Preload$86.90| MFR / Brand | SKF |
|---|---|
| MPN | 7204 ACX/P4ADGA |
| Model | 7204 ACX / P4ADGA |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 20 mm |
| OD | 47 mm |
| Width | 14 mm |
| Material | Chrome Steel |
|---|---|
| Series | 7200 |
| Condition | New |
| Preload | Light |
| Base Number | 7204 |
| Industry Terms | Spindle bearing; super-precision bearing; precision angular contact bearing; machine tool bearing |
| Common Misspellings | 7204 ACXGA P4A; 7204 ACX GA P4A; 7204AXCGA/P4A; 72 04 ACXGA; 7204ACXG4/P4A |
| Application Types | Machine tool spindles; grinding spindles; high-speed motor spindles; precision rotary tables |
| Overall Width | 14 mm |
| Mpn Variants | 7204 ACXGA/P4A; 7204-ACXGA/P4A; 7204 ACX/P4ADGA; 7204ACXP4A; 7204ACXGAP4A; 7204A |
| Arrangement Configuration | Universally matchable single bearing |
| Precision Class | P4A |
| Precision Rating | P4A |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 25° |
| Mounting Arrangement | Universally matchable — back-to-back, face-to-face or tandem |
| Bearing Material | Bearing steel |
| Cross Reference 1 | Timken/Fafnir 3MM204WICRSUL |
|---|---|
| Cross Reference 2 | FAG B7204-E-T-P4S-UL |
| Cross Reference 3 | NSK 7204A5TRSULP4 |
| Cross Reference 4 | RHP 7204X3TRSULP4 |
SKF 7204 ACXGA/P4A super-precision, universally matchable single-row angular contact ball bearing. Bore Diameter: 20 mm. Outside Diameter: 47 mm. Overall Width: 14 mm. Contact Angle: 25°. Precision Class: P4A. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Bearing Material: Bearing steel.
72 — ISO dimension series 02. A 20 mm bore carries a 47 mm outside diameter in a 14 mm section.
04 — bore code. 04 × 5 = 20 mm.
AC — 25° contact angle. The higher angle carries more axial load and raises axial stiffness.
GA — universally matchable, extra light preload.
P4A — SKF super-precision tolerance class: P4 dimensional accuracy with running accuracy held tighter still.
Contact Angle: 25°. Radial load is carried together with axial load acting in one direction, with the steeper load line favouring thrust capacity and axial stiffness over top speed.
ISO dimension series 02 at a 20 mm bore is the heavier of the two common super-precision sections, giving a 47 mm outside diameter against the 42 mm of the 70-series at the same bore.
Closure Type: Open, supplied unlubricated and preserved for spindle-shop cleaning and grease or oil charging at build.
Mounting Arrangement: universally matchable back-to-back, face-to-face or tandem. Bore Type: Straight. Harmonization Code: 8482.10.50.
Unit Quantity: 1 Pc. A single universally matchable bearing, usable alone or paired with any other GA bearing of the same designation.
Same envelope, same 25° angle, same super-precision class: Timken/Fafnir 3MM204WICRSUL, FAG B7204-E-T-P4S-UL, NSK 7204A5TRSULP4, RHP 7204X3TRSULP4.
Preload is part of the identity. GB is the light and GC the medium preload on the same envelope.
