Availability:
2 in stock
Angular contact ball bearing, super precision, ABEC 7/P4, 12 mm bore x 28 mm OD x 8 mm width, 25° contact angle, extra light preload pair.
List Price
$136.01
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 7001ACDP4ADGA |
| GTIN | 7316577067104 |
| Model | 7001-ACD-P4A-DGA 7001A |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 12 mm |
| OD | 28 mm |
| Width | 8 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7000 |
| Preload | Extra light |
| Base Number | 7001 |
| Mpn Variants | 7001ACDP4ADGA, 7001-ACD/P4ADGA, 7001-ACD-P4A-DGA, 7001A |
| Precision Class | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 25° |
| Bearing Material | Bearing Steel |
| Cross Reference 1 | FAG B7001-E-T-P4S-DUL – 25°, same envelope, light preload |
|---|---|
| Cross Reference 2 | Fafnir 3MM9101WI DUL – 25°, same envelope, light preload |
| Cross Reference 3 | SKF 7001 ACD/P4ADGB – same bearing, light preload |
| Cross Reference 4 | SKF 7001 ACD/P4ADGC – same bearing, medium preload |
| Cross Reference 5 | SKF 7001 CD/P4ADGA – 15° contact angle, extra light preload |
| Cross Reference 6 | SKF 7001 ACD/HCP4ADGA – same, hybrid ceramic balls |
Angular contact ball bearing, super precision, straight bore, 12 mm bore, 28 mm outside diameter, 8 mm width, supplied as a matched preload pair.
7001 — SKF angular contact ball bearing, extra light 70-series, ISO envelope 12 x 28 x 8 mm.
ACD — 25° contact angle, C design.
P4A — ABEC 7 / P4 precision, execution A.
DGA — extra light preload.
Bore Diameter: 12 mm. Outside Diameter: 28 mm. Overall Width: 8 mm. Contact Angle: 25°. Precision Class: ABEC 7 / P4. Preload: Extra light. Closure Type: Open. Rolling Elements: Ball. Bore Type: Straight. Bearing Material: Bearing Steel. GTIN: 7316577067104. Ground and matched as an extra light preload pair, this bearing mounts in duplex arrangements typical of spindle and precision machine applications.
Unit Quantity: 2 Pcs. Sold as a matched preload pair.
Same envelope and 25° contact angle at a different preload: FAG B7001-E-T-P4S-DUL and Fafnir 3MM9101WI DUL at light preload, SKF 7001 ACD/P4ADGB at light preload and SKF 7001 ACD/P4ADGC at medium preload. The SKF 7001 CD/P4ADGA is a 15° bearing, a related size rather than a substitution.
