Angular Contact Ball Bearing - 15 mm ID, 35 mm OD, 11 mm Width, 15° Contact Angle, Light Preload, ABEC 7 / P4, Phenolic Cage, Open.$54.46
Spindle Bearing - Angular Contact, 15 mm ID, 35 mm OD, 11 mm Width, 15° Contact Angle, Phenolic Cage, P4S, Universal Light Preload$51.79
Spindle Bearing - Angular Contact, 15 mm ID, 35 mm OD, 11 mm Width, 15° Contact Angle, Phenolic Cage, P4S, Universal Light Preload$51.87
Super-Precision Angular Contact Ball Bearing Duplex Pair - 15 mm ID, 35 mm OD, 11 mm Width, 22 mm Total, 15 Degree, Light Preload$71.24| MFR / Brand | RHP |
|---|---|
| MPN | 7202TDULP4 |
| Model | 7202 T DUL P4 / 7202TUEP7 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 15 mm |
| OD | 35 mm |
| Width | 11 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7200 |
| Lubricant | Oil |
| Preload | Light |
| Min Temp | -30 °C |
| Cage Type | Phenolic |
| Dynamic Load Rating | 7.8 kN |
| Static Load Rating | 3.8 kN |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 0.10 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal |
| Limiting Speed | 40000 rpm |
| Cross Reference 1 | SKF 7202 CD/P4DGA |
|---|---|
| Cross Reference 2 | NSK 7202CTYNDULP4 |
