Availability:
6 in stock
Angular contact ball bearing, 130 x 200 x 33 mm, 25° contact angle, light preload. Universally matchable single, laminated phenolic cage, open.
List Price
$667.36
6 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | RHP |
|---|---|
| MPN | 7026ETSULP4 |
| Model | 7026 E T SUL P4 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 130 mm |
| OD | 200 mm |
| Width | 33 mm |
| Series | 7000 |
|---|---|
| Base Number | 7026 |
| Bore Shaft Size | 130 mm |
| Mpn Variants | 7026ETSULP4, 7026-E-T-SUL-P4, 7026 E T SUL P4, 7026E, 3MM9126WICR-SUL, 126HDL |
| Closure Type | Open |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Part Number | 7026ETSULP4 |
| Cross Reference 6 | RHP 7026CTSULP4 (related size, 15° contact angle) |
|---|
RHP 7026ETSULP4 super precision single-row angular contact ball bearing. Series: 7000, ISO dimension series 10. Bore: 130 mm. Outside diameter: 200 mm. Width: 33 mm. Straight bore, open on both faces, ball rolling elements in chrome bearing steel to SAE 52100. Country of origin as recorded: United Kingdom.
Contact Angle: 25°. Cage: laminated phenolic resin, machined and outer-ring guided. Grouping: SU, single universally ground. Preload: L, light. Precision Grade: P4, equal to RHP EP7 and ABEC 7. Searchable forms include 7026ETSULP4, 7026-E-T-SUL-P4, 7026 E T SUL P4 and the Fafnir cross 3MM9126WICR-SUL.
Dynamic Load Rating: 122 kN. Static Load Rating: 130 kN. Limiting speed with grease: 5,800 rpm. Limiting speed with oil/air: 8,900 rpm. A 25° contact angle carries more thrust and less speed than a 15° bearing on the same envelope. Light preload is the most widely used level, holding rolling contact without the heat generation of a medium or heavy setting. Axial stiffness as a light-preload matched pair: 396 N/µm, with 1,570 N of axial preload. The outer-ring guided phenolic cage runs to 120 °C continuously.
Sold as single bearings. Universal face control lets a pair mount back-to-back, face-to-face or in tandem, with the preload set at manufacture and no ground spacers required.
Abutment diameters from the RHP super precision tables: shaft shoulder d1 minimum 140 mm, housing shoulder D1 maximum 190 mm, D2 maximum 194 mm. Fillet radius r minimum 2.5 mm, r1 minimum 1.0 mm. Effective load centre a = 55.0 mm. Internal free volume 131.8 cm³. Lubrication jet pitch circle 156.2 mm. Mass 3.229 kg.
Same-specification equivalents at 25° and light preload: FAG B7026-E-T-P4S-UL, Fafnir 3MM9126WICR-SUL, NSK 7026A5TRSULP4, Fafnir 126HDL. SKF 7026 ACD/P4A is the equivalent universally matchable 25° execution. RHP 7026CTSULP4 is a related size at 15°.
