This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Double-Row Angular Contact Ball Bearing, 55 x 100 x 33.3 mm, 30 Degree Contact Angle, Open, Normal Clearance, 1 Pc$37.31
Angular Contact Ball Bearing, 55x100x21 mm, 15° Angle, ABEC 7$113.90
Super-Precision Angular Contact Spindle Bearing, 55x100x21 mm, 15° Contact Angle, Universally Ground Single, Medium Preload, ABEC 7 (P4)$128.78
Angular Contact Ball Bearing Matched Pair - Straight Bore, 55 mm ID, 100 mm OD, 21 mm Width Each, Open, 30° Contact Angle, Back-To-Back Duplex, ABEC 5$217.88| MFR / Brand | NSK |
|---|---|
| MPN | 3211J |
| Model | 3211 5211 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 55 mm |
| OD | 100 mm |
| Width | 33.3 mm |
| Series | 3200 |
|---|---|
| Material | Bearing Steel |
| Min Temp | -30 °C |
| Cage Type | Stamped |
| Dynamic Load Rating | 68 kN / 15300 lbf |
| Static Load Rating | 53 kN / 11900 lbf |
| Precision Rating | ABEC 1 / P0 |
| Rolling Elements | Balls |
| Max Temp | 120 °C |
| Item Weight | 2.56 lbs |
| Cage Material | Steel |
| Number Of Rows | 2 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 30° |
| Internal Clearance | CN |
| Limiting Speed | 5000 rpm |
| Cross Reference 1 | SKF 3211 A |
|---|---|
| Cross Reference 2 | FAG 3211-B-TVH |
| Cross Reference 3 | NTN 5211 |
