Fafnir 2MM222WI-SUL super-precision angular contact ball bearing, 110x200x38 mm, 15° contact angle, ABEC 7 / P4, universally ground single, light preload.
List Price
$706.44
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Fafnir |
|---|---|
| MPN | 2MM222WI-SUL |
| Model | 2MM 222 WI SUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 110 mm |
| OD | 200 mm |
| Width | 38 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7200 |
| Preload | Light |
| Base Number | 7222 |
| Industry Terms | Spindle bearing, super precision angular contact, universally ground single, machine tool bearing, ABEC 7 bearing |
| Common Misspellings | Fafner 2MM222WI, Faffnir 2MM222WISUL, Timkin 2MM222WI, 2M222WI |
| Application Types | Machine tool spindles, large grinding spindles, precision boring mills, heavy rotary tables |
| Bore Shaft Size | 110 mm (4.3307 in) |
| Mpn Variants | 2MM222WI-SUL, 2MM222WISUL, 2MM-222-WI-SUL, 2MM 222 WI SUL, 2MM222WI SUL |
| Precision Class | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 15° |
| Part Number | 2MM222WI-SUL |
| Cross Reference 1 | 7222 C/CD/CT P4 (carton Replaces) |
|---|---|
| Cross Reference 2 | Barden 222-H (carton Replaces) |
| Cross Reference 3 | NDH Q20222 (carton Replaces) |
Fafnir (Timken) 2MM222WI-SUL super-precision angular contact ball bearing, single row, universally ground single. Bore 110 mm, outside diameter 200 mm, width 38 mm, ISO 7222 envelope. Unit Quantity: 1 Pc.
2MM — 15° contact angle (2MM = 15°, 3MM = 25°); MM is Timken super-precision class P4, ABEC 7.
222 — ISO 72 dimension series, 7222 envelope, 110 x 200 x 38 mm.
WI — low shoulder on both rings, the super-precision angular contact family.
SU — single, universally ground.
L — light preload.
Bore Diameter: 110 mm.
Outside Diameter: 200 mm.
Width: 38 mm.
Contact Angle: 15°.
Precision Class: ABEC 7 / P4.
Preload: Light.
Number Of Rows: 1.
Closure Type: Open.
Country of Origin: United States.
Bore Type: Straight. Arrangement: single bearing with flush-ground faces (universally ground).
Carton cross-designations: 7222 C/CD/CT P4; Barden 222-H; NDH Q20222. MPN Variants: 2MM222WI-SUL; 2MM222WISUL; 2MM-222-WI-SUL; 2MM 222 WI SUL; 2MM222WI SUL.
Bore 110 mm, outside diameter 200 mm, width 38 mm.
15° contact angle and Timken class P4 (ABEC 7).
SU is a single, universally ground bearing and L is light preload.
