Super precision angular contact ball bearing, 60 x 110 x 22 mm, 15° contact angle, phenolic cage, ABEC 7/9. Open, chrome steel, for spindle service.
List Price
$151.76
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Fafnir |
|---|---|
| MPN | 2MM212WI CR |
| GTIN | 087796070677 |
| Model | 2MM 212 WI / ABEC7 / 7212-C |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 60 mm |
| OD | 110 mm |
| Width | 22 mm |
| Material | Bearing Steel |
|---|---|
| Series | 200WI |
| Dynamic Load Rating | 71,000 N |
| Static Load Rating | 48,900 N |
| Precision Rating | ISO P4S (ABEC 7/9) |
| Rolling Elements | Ball |
| Item Weight | 0.79 kg (1.74 lb) |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Limiting Speed | 13,200 rpm grease; 26,400 rpm oil |
| Base Number | 212 |
| Overall Width | 22 mm |
| Mpn Variants | 2MM212WI-CR; 2MM212WICR; 2MM212WI; 2MM-212-WI-CR; 2MM 212 WI CR; 7212C-T-P4S |
| Precision Class | ABEC 7 / P4 |
| Additional Attributes | Max Housing Fillet Radius: 1.5 mm; Shaft Backing Shoulder Diameter: 69.3 mm; Housing Backing Shoulder Diameter: 101.4 mm |
| Bearing Material | Chrome Steel |
| Cross Reference 1 | SKF 7212 CD/P4A |
|---|---|
| Cross Reference 2 | FAG B7212-C-T-P4S |
| Cross Reference 3 | NSK 7212CTRP4 |
| Cross Reference 4 | NTN 7212UC/GNP4 |
| Cross Reference 5 | SKF 7212 ACD/P4A - 25 deg contact angle, not 15 deg |
Fafnir 2MM212WI-CR super precision angular contact ball bearing. Series: 200WI. Base Number: 212. Bore Diameter: 60 mm. Outside Diameter: 110 mm. Overall Width: 22 mm. Contact Angle: 15°. Precision Class: ABEC 7 / P4. Cage Material: Phenolic. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Number Of Rows: 1. Bearing Material: Chrome Steel. Item Weight: 0.79 kg (1.74 lb). Unit Quantity: 1 Pc. GTIN: 087796070677.
2MM — Fafnir super precision execution at a 15° contact angle, built to ISO P4S.
212 — 200WI dimension series at a 60 mm bore. The ISO equivalent is 7212.
WI — low shoulder on both rings, the form used for duplex mounting.
CR — phenolic cage.
Dynamic Load Rating: 71,000 N. Static Load Rating: 48,900 N. Limiting Speed: 13,200 rpm grease; 26,400 rpm oil.
Contact Angle: 15°. The shallow angle favours speed and radial stiffness over thrust capacity, and it is the reason a 60 mm bore bearing reaches 26,400 rpm on oil.
Cage Material: Phenolic. Fabric-base phenolic is light and low in inertia, so the cage tolerates rapid acceleration and holds oil in its own structure.
Precision Class: ABEC 7 / P4. Running accuracy at this class holds shaft position to a few microns, which is what the 200WI range is ground for.
Item Weight: 0.79 kg (1.74 lb).
Max Housing Fillet Radius: 1.5 mm. Shaft Backing Shoulder Diameter: 69.3 mm. Housing Backing Shoulder Diameter: 101.4 mm.
Unit Quantity: 1 Pc. One single bearing, WI form, with the low ring shoulders that let it be stacked with others of the same designation.
The ISO designation for this size is 7212 at P4 precision. Cross-Reference 1: SKF 7212 CD/P4A. Cross-Reference 2: FAG B7212-C-T-P4S. Cross-Reference 3: NSK 7212CTRP4. Cross-Reference 4: NTN 7212UC/GNP4. Related, 25° contact angle on the same 60 x 110 x 22 mm size: SKF 7212 ACD/P4A.
