BeckhoffAX5206-0000-0202Digital Compact Servo Drive, 2-Channel, 2 x 6 A Rated / 13 A Peak per Channel, 3 x 100-480 V AC, EtherCAT with OCT, Hardware 2.0

Name: Digital Compact Servo Drive, 2-Channel, 2 x 6 A Rated / 13 A Peak per Channel, 3 x 100-480 V AC, EtherCAT with OCT, Hardware 2.0
Brand: Beckhoff
SKU: BG3#XAPD3D
Price: 740.66 USD
Availability: InStock

Condition: Seller refurbished

Condition Note: Made In Germany, Tested

Availability:

1 in stock

Categories: Industrial Automation, Drives & Amplifiers

Two-channel Beckhoff AX5000 digital compact servo drive, 2 x 6 A rated / 13 A peak per channel, 3 x 100-480 V AC, EtherCAT with OCT multi-feedback. Hardware 2.0, firmware 2.10+.

Same day shipment

List Price

$740.66

1 in stock

Also Available From:

Need Help?
Click Here To Contact Support

Specifications

Key Specifications

MFR / Brand	Beckhoff
MPN	AX5206-0000-0202
Model	AX5206 0000 0202

Technical Specifications

Condition	Seller refurbished
Type	Servo Drive
Base Number	AX5206
Industry Terms	servo drive; servo amplifier; digital compact servo drive; 2-channel servo drive; dual axis drive; EtherCAT drive; AX5000 drive; motion controller amplifier
Common Misspellings	AX5206 0000 0202; AX52060000202; AX-5206; Beckoff AX5206; Beckhof AX5206; Bechhoff; AX5206-000-0202
Application Types	Multi-axis machine automation; packaging and labelling machinery; CNC and machine tools; robotics and gantries; printing and converting lines; PC-based control retrofits
Condition Note	Made In Germany, Tested
Number Of Phases	3-phase
Maximum Amperage	13 A peak per channel
Output Amperage	6 A rated per channel (2 x 6 A)
Mpn Variants	AX5206-0000-0202; AX520600000202; AX5206 0000 0202; AX5206-0000-020x
Manufacturer Status	Current product, regular delivery; Beckhoff preferred type
Compatible With Replaces	Beckhoff AX5206-0000-0202; supersedes AX5206-0000-0200 (earlier firmware); works with AX5805, AX57xx, AX5021 and AX5801-0200
Additional Attributes	Function: servo drive; Channels: 2 (independent, individually parameterisable rated current); DC link voltage: max 875 V DC; Feedback interfaces: SinCos 1 VPP, resolver, EnDat 2.1, HIPERFACE, BiSS B, OCT; System bus: EtherCAT; Drive profile: SERCOS to IEC 61800-7-204 (SoE); Hardware version: 2.0; Firmware version: 2.10 or later; Height without connectors: 274 mm (10.7874 in); Depth without connectors: 232 mm (9.1339 in); Width: 92 mm (3.6220 in); Ambient temperature (operation): 0 to 50 C (32 to 122 F); Approvals and markings: CE, cULus; Integrated components: power supply unit, EMC filter, DC link capacitors; Multi-axis connection: AX-Bridge supply and connection modules; Optional safety: AX58xx for EN ISO 13849-1 Cat 4 PL e, EN 61508 SIL 3, EN 62061 SIL CL3; Motor types supported: synchronous, linear, torque, asynchronous, voice coil; RoHS: compliant with exemption; REACH SVHC: lead; Country of manufacture: Germany; DC-link capacitance (reseller data, not on Beckhoff page): 470 uF; Power loss (reseller data): 160 W
Min Temp	0 °C (32 °F)
Max Temp	50 °C (122 °F)
Nominal Rated Input Voltage	3 x 100-480 V AC ±10%
Design Units	Metric
Part Number	AX5206-0000-0202
Communication Standard	EtherCAT

Cross-References

Cross Reference 1	AX5206-0000-0202 (hardware 2.0, firmware >= 2.10)
Cross Reference 2	AX5206-0000-0200 (hardware 2.0, firmware 2.06)

Seller Part Number: BG3#XAPD3D

Product Description

What this part is

The Beckhoff AX5206-0000-0202 is a two-channel digital compact servo drive from the AX5000 family, rated 2 x 6 A continuous with 13 A peak per channel from a 3 x 100-480 V AC ±10% supply and a DC link up to 875 V DC.

What these specs mean in practice

Power supply unit, EMC filter and DC link capacitors are integrated, so no external components are needed to run it. Communication is over EtherCAT using the SERCOS drive profile to IEC 61800-7-204 (SoE), and the multi-feedback interface accepts SinCos 1 VPP, resolver, EnDat 2.1, HIPERFACE, BiSS B and OCT one-cable technology. Because the two channels are independent, their rated current can each be matched to the connected motor, and synchronous, linear, torque, asynchronous and voice-coil motors all connect without extra hardware. The AX-Bridge system links multiple AX5000 units into a multi-axis group sharing supply, DC link and 24 V DC control voltage.

Decoding the designation

This -0202 variant is hardware version 2.0 with firmware 2.10 or later and is Beckhoff’s preferred type, compatible with AX5805, AX57xx, AX5021 and AX5801-0200.
