Availability:
7 in stock
Precision radial deep groove ball bearing, 20 x 42 x 12 mm, ABEC 7 / P4, open, phenolic crown cage, 8 x 1/4 in balls. NHBB R-104 in the 6004 envelope.
List Price
$61.07
7 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NHBB |
|---|---|
| MPN | R-104KEA7 |
| Model | R-104-KE-A7 |
| Bearing Type | Tapered Roller Bearing Cone, Open |
| ID | 20 mm |
| OD | 42 mm |
| Width | 12 mm |
| Base Number | R-104 |
|---|---|
| Mpn Variants | R-104KEA7, R-104-KE-A7, R104KEA7, 6004-P4, 6004 T P4, R-104 |
| Precision Class | ABEC 7 / P4 |
| Additional Attributes | Ball complement: 8 x 1/4 in. Inner land diameter: 1.075 in. Outer land diameter: 1.375 in. Max fillet radius: 0.024 in. |
| Cage Type | Crown, inner land piloted |
| Dynamic Load Rating | 1,900 lbf |
| Static Load Rating | 990 lbf |
| Precision Rating | ABEC 7 / P4 |
| Series | R (Metric Radial) |
| Rolling Elements | Ball |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Cross Reference 1 | SKF 6004/P4 – cage differs |
|---|---|
| Cross Reference 2 | NSK 6004P4 – cage differs |
| Cross Reference 3 | FAG 6004-P4 – cage differs |
NHBB R-104KEA7 is a precision single-row radial (deep groove) ball bearing in the 6004 envelope, built by NHBB’s HiTech Division. Bore Diameter: 20 mm. Outside Diameter: 42 mm. Overall Width: 12 mm. Precision Class: ABEC 7 / P4. Closure Type: Open.
R — NHBB radial ball bearing type.
104 — dimension series 10, 20 mm bore: the 6004 envelope.
KE — crown-type cage, inner land piloted, phenolic.
A7 — ABEC 7 tolerance.
Dynamic Load Rating: 1,900 lbf. Static Load Rating: 990 lbf. Rolling Elements: 8 balls, 1/4 in diameter. Cage Material: Phenolic. Cage Type: Crown, inner land piloted. The ABEC 7 grade and phenolic crown cage suit high-speed, low-vibration spindle and instrument duty.
Maximum shaft or housing fillet radius: 0.024 in. Inner land diameter: 1.075 in. Outer land diameter: 1.375 in. Bore Type: Straight. Snap ring: No.
Unit Quantity: 1 Pc. Number Of Rows: 1.
Cross-references: SKF 6004/P4, NSK 6004P4 and FAG 6004-P4 are 6004 P4 bearings; cage execution differs between makers.
