Availability:
1 in stock
SNFA VEX50 7CE1 DUL angular contact ball bearing duplex pair, 50x80x16 mm each, 32 mm across the set, 15° contact angle, light preload, ABEC 7, 2 Pcs.
List Price
$268.99

1 in stock
On the Shelf & Ready to Ship
Ships same day by 6pm ET

No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| MPN | VEX50 7CE1 DUL |
| Model | VEX507CE1 DUL 7010 |
| Bearing Type | Super Precision Angular Contact Ball Bearing, Open, both faces |
| ID | 50 mm |
| OD | 80 mm |
| Width | 16 mm per bearing |
| Material | Bearing steel |
|---|---|
| Series | VEX (SNFA high-speed E design, ISO 70xx series) |
| Lubricant | Oil or grease |
| Preload | Light |
| Base Number | VEX50 7CE1 |
| Industry Terms | Super precision angular contact bearing, high speed spindle bearing, duplex universal pair, machine tool bearing, phenolic cage bearing, VEX series |
| Common Misspellings | VEX 50 7CE1DUL, VEX50 7CEI DUL, VEX-50-7CE1-DUL, SNFA VEX50 7CE1 DLU, angular contant angle bearing |
| Application Types | High-speed machine tool spindles, grinding spindles, milling heads, precision turning spindles, high-frequency motor spindles |
| Bore Shaft Size | 50 mm (1.9685 in) |
| Mpn Variants | VEX50 7CE1 DUL, VEX50-7CE1-DUL, VEX507CE1DUL, VEX 50 7CE1 DUL, VEX50/NS 7CE1 DUL, VEX50 7 CE1 DUL |
| Manufacturer Status | SNFA is part of the SKF Group; the VEX high-speed E design continues as the SKF 70..E series |
| Arrangement Configuration | Universally matchable duplex pair |
| Precision Class | ABEC 7 / P4 |
| Cage Type | Machined, outer-ring guided |
| Rolling Elements | Steel balls |
| Cage Material | Phenolic |
| Number Of Rows | 1 row per bearing |
| Bore Type | Straight (cylindrical) |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 15° |
| Part Number | VEX50 7CE1 DUL |
| Cross Reference 1 | SKF VEX 50 /NS 7CE1 DUL |
|---|---|
| Cross Reference 2 | SKF 7010 CD/P4ADGA - conventional 7010, 15 deg |
| Cross Reference 3 | NSK 7010CTYNDULP4 - conventional 7010, 15 deg |
| Cross Reference 4 | 7010 - ISO base number, 50x80x16 mm |
| Cross Reference 5 | SNFA EX50 7CE1 DDL - EX series, medium preload |
| Cross Reference 6 | VEX50 7CE3 - 25 deg contact angle |
SNFA VEX50 7CE1 DUL super-precision angular contact ball bearing, supplied as a universally matchable duplex pair (2 Pcs) with light preload. Bore 50 mm, outside diameter 80 mm, width 16 mm per bearing and 32 mm across the pair. Open on both faces, straight bore, one row of steel balls per bearing, machined phenolic cage guided on the outer ring.
VEX — SNFA high-speed E design in the ISO 70xx dimension series. A VEX50 occupies the 7010 envelope, 50 x 80 x 16 mm.
7 — ABEC 7 tolerance class, equivalent to P4.
CE1 — 15° contact angle.
DUL — duplex universal set at light preload.
Bore Diameter: 50 mm.
Outside Diameter: 80 mm.
Width: 16 mm per bearing.
Total Width: 32 mm across the duplex pair.
Contact Angle: 15°.
Precision Class: ABEC 7 / P4.
Preload: Light.
Cage Material: Phenolic.
Cage Type: Machined, outer-ring guided.
Rolling Elements: Steel balls.
Closure Type: Open.
Unit Quantity: 2 Pcs.
Bore Type: Straight (cylindrical). Ring faces are ground so the universally matchable pair mounts back-to-back, face-to-face or in tandem. Preloaded sets carry no internal clearance specification.
Cross-references: SKF VEX 50 /NS 7CE1 DUL; SKF 7010 CD/P4ADGA (conventional 7010, 15°, light preload); NSK 7010CTYNDULP4 (conventional 7010, 15°, light preload); ISO base number 7010; SNFA EX50 7CE1 DDL (EX series, medium preload); VEX50 7CE3 (25° contact angle). SNFA is part of the SKF Group.
Bore 50 mm, outside diameter 80 mm, width 16 mm per bearing and 32 mm across the duplex pair.
DUL is a duplex universal set at light preload, so two bearings can be mounted back-to-back, face-to-face or in tandem.
CE1 gives a 15° contact angle and the 7 gives ABEC 7 / P4.
