Torrington 22218KCJW33 spherical roller bearing, 90 mm tapered bore x 160 mm OD x 40 mm wide, steel cage, W33 lube groove, normal clearance. Successor: 22218KEJW33.
List Price
$102.79
9 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Torrington |
|---|---|
| Model | 22218-KCJ-W33 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 90 mm |
| OD | 160 mm |
| Width | 40 mm |
| Series | 22200 |
|---|---|
| Lubricant | Oil/Grease |
| Dynamic Load Rating | 355,000 N (Successor 22218KEJW33 data) |
| Static Load Rating | 388,000 N (Successor 22218KEJW33 data) |
| Rolling Elements | Spherical Roller |
| Cage Material | Steel |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Snap Ring Included | No |
| Harmonization Code | 8482.30.00 |
| Internal Clearance | CN |
| Mpn Variants | 22218KCJW33, 22218-KCJ-W33, 22218 K CJ W33, 22218CKJ, 22218CKJW33 |
| Compatible With Replaces | Timken 22218KEJW33 (current successor design) |
| Additional Attributes | Successor 22218KEJW33 data: e factor 0.23; Y0 2.83; Y1 2.9; Y2 4.31; shaft backing shoulder 105 mm; housing backing shoulder 146 mm; max fillet radius 2 mm. Adapter sleeve: H318 |
| Design Units | Metric |
| Cross Reference 1 | Timken 22218KEJW33 |
|---|---|
| Cross Reference 2 | SKF 22218 EK |
| Cross Reference 3 | FAG 22218-E1-K |
| Cross Reference 4 | NSK 22218EAKE4 |
Torrington 22218KCJW33 double-row spherical roller bearing: 90 mm tapered bore, 160 mm outside diameter, 40 mm width, steel cage, W33 lubrication groove, normal clearance. Torrington is a Timken brand; the current Timken design is 22218KEJW33.
222 — spherical roller bearing, ISO dimension series 22.
18 — bore code. 18 × 5 = 90 mm bore.
K — 1:12 tapered bore for adapter-sleeve or tapered-journal mounting.
CJ — Torrington internal design with steel cage.
W33 — lubrication groove with three radial holes in the outer ring.
Bore Diameter: 90 mm. Outside Diameter: 160 mm. Overall Width: 40 mm. Bore Type: Tapered 1:12. Rolling Elements: Spherical Roller. Number Of Rows: 2. Cage Material: Steel. Internal Clearance: CN. Closure Type: Open. Lubricant: grease or oil.
Successor 22218KEJW33 data: Dynamic Load Rating: 355,000 N. Static Load Rating: 388,000 N. Reference Speed: 3,400 rpm grease; 4,100 rpm oil. e factor: 0.23. Y1: 2.9. Y2: 4.31. Y0: 2.83.
The spherical outer raceway lets the bearing self-align under shaft deflection while carrying heavy radial load and axial load in both directions. The W33 groove feeds grease or oil to the centre of both roller rows.
Successor 22218KEJW33 data: Shaft Backing Shoulder Diameter: 105 mm. Housing Backing Shoulder Diameter: 146 mm. Maximum Fillet Radius: 2 mm. Related part: H318 adapter sleeve with KM18 locknut and MB18 lockwasher.
Unit Quantity: 1 Pc. One complete bearing.
Same 90 × 160 × 40 mm tapered-bore, normal-clearance envelope: Timken 22218KEJW33, SKF 22218 EK, FAG 22218-E1-K, NSK 22218EAKE4, NTN 22218EAKW33.
