Availability:
2 in stock
Double-row spherical roller bearing, 40 x 80 x 23 mm, straight bore, CN clearance. Open, pressed steel cage, 1.5 degree permissible misalignment.
List Price
$42.47
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNR |
|---|---|
| Model | 22208J / 22208CJ |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 40 mm |
| OD | 80 mm |
| Width | 23 mm |
| Material | Chrome Steel |
|---|---|
| Series | 22200 |
| Lubricant | Grease or oil |
| Base Number | 22208 |
| Bore Shaft Size | 40 mm |
| Mpn Variants | 22208, 22208J, 22208CJ, 22208 J, 22208 CJ |
| Closure Type | Open |
| Cage Type | Pressed |
| Dynamic Load Rating | 96.5 kN |
| Static Load Rating | 90 kN |
| Rolling Elements | Spherical Roller |
| Item Weight | 0.52 kg (1.15 lb) |
| Cage Material | Pressed Steel |
| Number Of Rows | 2 |
| Bore Type | Straight |
| Internal Clearance | CN |
| Harmonization Code | 8482.30.00.80 |
| Part Number | 22208 |
| Maximum Permissible Misalignment | 1.5 degrees |
| Cross Reference 1 | SKF 22208 E (high-capacity design) |
|---|---|
| Cross Reference 2 | FAG 22208-E1-XL (high-capacity design) |
| Cross Reference 3 | NTN 22208EAD1 (high-capacity design) |
| Cross Reference 4 | Koyo 22208RHR (high-capacity design) |
| Cross Reference 5 | NSK 22208EAE4 (high-capacity design) |
SNR 22208 is a double-row spherical roller bearing with a straight bore. Manufacturer Part Number: 22208. Bearing Type: Spherical Roller Bearing. Series: 22200. Number Of Rows: 2. Rolling Elements: Spherical Roller. Bore Diameter: 40 mm. Outside Diameter: 80 mm. Overall Width: 23 mm. Bore Type: Straight. Closure Type: Open. Unit Quantity: 1 Pc.
22 — double-row spherical roller type in the ISO dimension series.
2 — width series.
08 — bore code, a 40 mm bore.
No suffix — normal internal clearance, CN.
Dynamic Load Rating: 96.5 kN. Static Load Rating: 90 kN. Internal Clearance: CN. Precision Class: P0, ABEC 1. Cage Material: Pressed Steel. Cage Type: Pressed. Bearing Material: Chrome bearing steel. Closure Type: Open. Maximum Permissible Misalignment: 1.5°. Lubricant: Grease or oil. Item Weight: 0.52 kg (1.15 lb). Harmonization Code: 8482.30.00.80. Design Units: Metric.
Bore Diameter: 40 mm. Outside Diameter: 80 mm. Overall Width: 23 mm. Bore Type: Straight, for a cylindrical shaft seat.
Same 40 x 80 x 23 mm envelope, current high-capacity designs with load ratings above this conventional design: SKF 22208 E, FAG 22208-E1-XL, NTN 22208EAD1, Koyo 22208RHR, NSK 22208EAE4. Searchable forms: 22208, 22208J, 22208CJ, 22208 J, 22208 CJ.
What size is the SNR 22208?Bore Diameter: 40 mm. Outside Diameter: 80 mm. Overall Width: 23 mm.
What are its load ratings?Dynamic Load Rating: 96.5 kN. Static Load Rating: 90 kN.
What internal clearance does it have?Internal Clearance: CN (normal).
