Spherical roller bearing, 75 mm tapered bore (1:12) x 130 mm OD x 31 mm wide, C3 clearance, pressed steel cages. Mounts on an H315 adapter sleeve (65 mm shaft).
List Price
$86.26
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 22215-CKJ/C3 |
| Model | 22215 CKJ C3 / 22215 CK/CCK/CCKJ |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 75 mm |
| OD | 130 mm |
| Width | 31 mm |
| Material | Bearing Steel |
|---|---|
| Base Number | 22215 |
| Overall Width | 31 mm |
| Mpn Variants | 22215-CKJ/C3, 22215-CKJ-C3, 22215CKJC3, 22215 CKJ C3, 22215CKJ |
| Additional Attributes | Mounts on H315 adapter sleeve (65 mm shaft), KM15 lock nut, MB15 lock washer |
| Series | 222 |
| Rolling Elements | Spherical Roller |
| Cage Material | Pressed steel |
| Number Of Rows | 2 |
| Bore Type | Tapered, 1:12 |
| Snap Ring Included | No |
| Internal Clearance | C3 |
| Harmonization Code | 8482.30.00 |
| Closure Type | Open |
| Cross Reference 1 | FAG 22215-K-C3 |
|---|---|
| Cross Reference 2 | NSK 22215K C3 |
| Cross Reference 3 | NTN 22215K C3 |
| Cross Reference 4 | Koyo 22215K C3 |
| Cross Reference 5 | Timken 22215K C3 |
| Cross Reference 6 | MRC 22215K C3 |
| Cross Reference 7 | SNR 22215K C3 |
SKF 22215-CKJ/C3 double-row spherical roller bearing with a 1:12 tapered bore, pressed steel cages and C3 internal clearance. Unit Quantity: 1 Pc. One complete bearing: inner ring, two roller rows with cages, and outer ring.
22215 — ISO spherical roller bearing, 222 series, bore code 15: 75 mm bore, 130 mm outside diameter, 31 mm width.
K — tapered bore, taper 1:12.
J — pressed steel cages.
C3 — radial internal clearance greater than normal.
Rolling Elements: Spherical Roller. Number Of Rows: 2. Series: 222. Cage Material: Pressed steel. Internal Clearance: C3. Closure Type: Open. Bore Type: Tapered, 1:12. Harmonization Code: 8482.30.00.
Bore Diameter: 75 mm. Outside Diameter: 130 mm. Overall Width: 31 mm. Mounts on an H315 adapter sleeve for a 65 mm shaft, with a KM15 lock nut and MB15 lock washer. The tapered bore also seats directly on a matching 1:12 tapered journal.
Cross-references on the ISO 22215 envelope, tapered bore, C3 clearance: FAG 22215-K-C3, NSK 22215K C3, NTN 22215K C3, Koyo 22215K C3, Timken 22215K C3, MRC 22215K C3, SNR 22215K C3. SKF E-design executions such as 22215 EK share this envelope with a different internal design and different ratings.
Bore Diameter: 75 mm. Outside Diameter: 130 mm. Overall Width: 31 mm.
Pressed steel cages, from the J code.
An H315 adapter sleeve for a 65 mm shaft, with a KM15 lock nut and MB15 lock washer.
