Availability:
1 in stock
Koyo 22216PCW33 spherical roller bearing, 80 mm straight bore, 140 mm OD, 33 mm width, W33 lubrication groove, normal (CN) clearance. 22200 series, open.
List Price
$68.65
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Koyo |
|---|---|
| MPN | 22216PCW33 |
| Model | 22216PCW33 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 80 mm |
| OD | 140 mm |
| Width | 33 mm |
| Series | 22200 |
|---|---|
| Material | Bearing Steel |
| Rolling Elements | Spherical Roller |
| Number Of Rows | 2 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.30.00 |
| Internal Clearance | CN |
| Relubrication | W33 groove and three holes in outer ring |
| Mpn Variants | 22216PCW33, 22216 PC W33, 22216-PC-W33, 22216CC, 22216CJ, 22216C |
| Lubricant | grease or oil |
| Cross Reference 1 | SKF 22216 E (E design) |
|---|---|
| Cross Reference 2 | FAG 22216-E1 (E1 reinforced design) |
| Cross Reference 3 | NSK 22216EAE4 (EA design, E4 = W33) |
Koyo 22216PCW33 double-row spherical roller bearing, 22200 series, 80 mm straight bore, 140 mm outside diameter, 33 mm wide, with a W33 lubrication groove and three holes in the outer ring, normal (CN) radial internal clearance, open. Unit Quantity: 1 Pc.
22216 — 222 series spherical roller bearing, bore code 16 = 80 mm bore, 140 mm OD, 33 mm width.
W33 — lubrication groove and three lubrication holes in the outer ring.
No clearance suffix — normal (CN) radial internal clearance.
Bore Diameter: 80 mm. Outside Diameter: 140 mm. Overall Width: 33 mm. Series: 22200. Bore Type: Straight. Number Of Rows: 2. Rolling Elements: Spherical Roller. Internal Clearance: CN. Closure Type: Open. Lubricant: grease or oil. Bearing Material: Bearing steel. Country of Origin: Japan. Unit Quantity: 1 Pc.
Bore: 80 mm, straight (cylindrical). Outside Diameter: 140 mm. Width: 33 mm. The W33 groove distributes lubricant around the outer ring; three radial holes carry it to the rollers.
Straight-bore 22216 with lubrication groove under other makers: SKF 22216 E (E design), FAG 22216-E1 (E1 reinforced design), NSK 22216EAE4 (EA design, E4 = W33). Also listed as 22216 PC W33, 22216-PC-W33, 22216CC, 22216CJ, 22216CCJ and 22216C.
80 mm straight bore, 140 mm outside diameter, 33 mm width.
W33 is a lubrication groove and three lubrication holes in the outer ring.
Normal (CN) radial internal clearance.
