Double-row spherical roller bearing, 80 x 140 x 33 mm, cylindrical bore, W33 lubrication groove. Pressed steel window cage, CN clearance, open.
List Price
$99.39
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 22216-CCJ/W33 |
| Model | 22216 CCJ W33 / 22216C 22216CC 22216CJ 22216CCJ |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 80 mm |
| OD | 140 mm |
| Width | 33 mm |
| Material | Bearing steel |
|---|---|
| Series | 222 |
| Bore | Straight Bore |
| Base Number | 22216 |
| Relubrication | W33 annular groove in the outer ring with three radial holes |
| Mpn Variants | 22216-CCJ/W33; 22216-CCJ-W33; 22216CJ; 22216CCW33; 22216 CC/W33 |
| Cage Type | Window type, inner-ring guided |
| Rolling Elements | Spherical Roller |
| Cage Material | Pressed steel |
| Number Of Rows | 2 |
| Bore Type | Cylindrical |
| Snap Ring Included | Without Snap Ring |
| Internal Clearance | CN |
| Lubricant | Grease or oil |
| Harmonization Code | 8482.30.00.80 |
| Bearing Material | Bearing steel |
| Closure Type | Open |
| Cross Reference 1 | Torrington 22216CJW33 |
|---|---|
| Cross Reference 2 | NTN 22216 |
| Cross Reference 3 | Koyo 22216RW33 |
| Cross Reference 4 | FAG 22216-E1 (reinforced E design) |
| Cross Reference 5 | NSK 22216EAE4 (reinforced E design) |
| Cross Reference 6 | Timken 22216EJW33 (reinforced E design) |
SKF 22216 CC/W33 double-row spherical roller bearing, 80 x 140 x 33 mm, with a cylindrical bore, pressed steel window cage and W33 lubrication groove. Unit Quantity: 1 Pc, open on both faces.
22216 — the 222 spherical roller series at an 80 mm bore.
CC — SKF’s pressed steel window cage, guided on the inner ring.
W33 — an annular groove machined into the outer ring outside diameter with three radial holes through to the rolling elements.
No K — cylindrical bore.
No clearance suffix — normal radial internal clearance, CN.
Bore Diameter: 80 mm. Outside Diameter: 140 mm. Overall Width: 33 mm. Number Of Rows: 2. Rolling Elements: Spherical Roller. Bore Type: Cylindrical. Cage Material: Pressed steel. Cage Type: Window type, inner-ring guided. Internal Clearance: CN. Closure Type: Open. Lubricant: Grease or oil. Bearing Material: Bearing steel. Series: 222. Base Number: 22216. Groove width: 6 mm. Lubrication hole diameter: 3 mm.
Shaft abutment diameter: 91 mm minimum. Housing abutment diameter: 129 mm maximum. Shaft and housing fillet radius: 2 mm maximum. Bearing chamfer r1,2: 2 mm minimum. Lubrication: W33 annular groove in the outer ring with three radial holes.
Cross-Reference 1: Torrington 22216CJW33. Cross-Reference 2: NTN 22216. Cross-Reference 3: Koyo 22216RW33. Cross-Reference 4: FAG 22216-E1, reinforced E design. Cross-Reference 5: NSK 22216EAE4, reinforced E design; the E4 suffix is the same groove-and-three-holes feature as SKF’s W33. Cross-Reference 6: Timken 22216EJW33, reinforced E design. Searchable forms: 22216-CCJ/W33, 22216-CCJ-W33, 22216CJ, 22216CCW33, 22216.
Cylindrical. There is no K in the designation, and the bore is 80 mm.
W33 is an annular groove 6 mm wide in the outer ring outside diameter with three radial holes of 3 mm diameter through to the rolling elements.
A pressed steel window cage guided on the inner ring, with normal radial internal clearance, CN.
