Double-row spherical roller bearing, 75 mm bore, 160 mm OD, 37 mm width, 1:12 tapered bore, glass-fibre reinforced polyamide cage. FAG 21315EK.TVPB.
List Price
$101.69
4 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 21315EK.TVPB |
| Model | 21315 E K TVPB |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 75 mm |
| OD | 160 mm |
| Width | 37 mm |
| Material | Chrome Steel |
|---|---|
| Series | 213 |
| Base Number | 21315E |
| Industry Terms | Spherical roller bearing; self-aligning roller bearing; taper bore roller bearing; pendelrollenlager |
| Common Misspellings | 21315 EK TVBP; 21315-EKTVP; 21315EK.TVP; 213 15EK |
| Application Types | Fans and blowers; conveyors; crushers and screens; gearboxes; paper machinery; pumps |
| Bore Shaft Size | 75 mm (2.953 in) tapered bore 1:12, measured at the small end |
| Locking Method | 1:12 taper bore on adapter sleeve H2315 with KM15 locknut and MB15 tab washer (not included) |
| Mpn Variants | 21315EK.TVPB; 21315-E-K-TVPB; 21315 E K TVPB; 21315EKTVPB; 21315EK; 21315E; 21315 |
| Compatible With Replaces | Adapter sleeve H2315 (65 mm shaft); locknut KM15; tab washer MB15 |
| Additional Attributes | Adapter sleeve H2315; locknut KM15; tab washer MB15; reinforced E design |
| Rolling Elements | Spherical |
| Cage Material | Glass-fibre reinforced polyamide |
| Number Of Rows | 2 |
| Bore Type | Tapered |
| Snap Ring Included | No |
| Harmonization Code | 8482.30.00 |
| Internal Clearance | CN |
| Part Number | 21315EK.TVPB |
| Cross Reference 1 | SKF 21315 EK - steel cage |
|---|---|
| Cross Reference 2 | NSK 21315EAKE4 - steel cage |
FAG 21315EK.TVPB is a double-row spherical roller bearing, 75 mm bore, 160 mm outside diameter, 37 mm width, with a 1:12 tapered bore and a glass-fibre reinforced polyamide cage. Unit Quantity: 1 Pc, bearing only.
213 — FAG narrow-section double-row spherical roller bearing series.
15 — bore code, 15 x 5 = 75 mm.
E — reinforced design with higher load rating.
K — 1:12 tapered bore.
TVPB — glass-fibre reinforced polyamide cage.
Bore Diameter: 75 mm (2.953 in), tapered 1:12, measured at the small end. Outside Diameter: 160 mm. Overall Width: 37 mm. Number Of Rows: 2. Rolling Elements: Spherical Roller. Cage Material: Glass-fibre reinforced polyamide. Internal Clearance: CN. Seal Type: Open. Series: 213.
Mounting Arrangement: 1:12 tapered bore on adapter sleeve H2315 (65 mm shaft) with KM15 locknut and MB15 tab washer.
Cross-references: SKF 21315 EK, steel cage; NSK 21315EAKE4, steel cage.
75 mm bore x 160 mm outside diameter x 37 mm width.
A 1:12 tapered bore (K), 75 mm at the small end, matching adapter sleeve H2315.
TVPB is the FAG code for a glass-fibre reinforced polyamide cage.
