Availability:
1 in stock
Self-aligning ball bearing, 60 mm tapered bore (1:12) x 130 mm OD x 31 mm wide, SKF E design, glass-fibre polyamide cage. Mounts on an H312 adapter sleeve.
List Price
$76.48
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 1312EKTN9 |
| Model | 1312E |
| Bearing Type | Self Aligning Ball Bearing, Open |
| ID | 60 mm |
| OD | 130 mm |
| Width | 31 mm |
| Material | Bearing Steel |
|---|---|
| Base Number | 1312 |
| Overall Width | 31 mm |
| Mpn Variants | 1312-EKTN9, 1312EKTN9, 1312 EKTN9, 1312EK, 1312E, 1312K |
| Additional Attributes | Mounts on H312 adapter sleeve (55 mm shaft), KM12 lock nut, MB12 lock washer |
| Series | 13 |
| Rolling Elements | Ball |
| Cage Material | Polyamide, glass-fibre reinforced |
| Number Of Rows | 2 |
| Bore Type | Tapered, 1:12 |
| Snap Ring Included | No |
| Internal Clearance | CN |
| Cross Reference 1 | FAG 1312-K-TVH |
|---|---|
| Cross Reference 2 | NSK 1312K |
| Cross Reference 3 | NTN 1312K |
| Cross Reference 4 | Koyo 1312K |
| Cross Reference 5 | Timken 1312K |
| Cross Reference 6 | SNR 1312K |
SKF 1312-EKTN9 double-row self-aligning ball bearing, SKF E design, with a 1:12 tapered bore and a glass-fibre reinforced polyamide cage. Bore Diameter: 60 mm. Outside Diameter: 130 mm. Overall Width: 31 mm.
1312 — ISO self-aligning ball bearing, 13 series, bore code 12: 60 mm bore, 130 mm outside diameter, 31 mm width.
E — SKF E design, the current internal design on this envelope.
K — tapered bore, taper 1:12.
TN9 — glass-fibre reinforced polyamide cage.
Rolling Elements: Ball. Number Of Rows: 2. Both ball rows run in a common spherical outer raceway, so the bearing self-aligns to shaft deflection and housing misalignment. Cage Material: Polyamide, glass-fibre reinforced. Internal Clearance: CN, normal radial clearance. Closure Type: Open.
Bore Type: Tapered, 1:12. Mounts on an H312 adapter sleeve for a 55 mm shaft, with a KM12 lock nut and MB12 lock washer. The tapered bore also seats directly on a matching 1:12 tapered journal.
Unit Quantity: 1 Pc. One complete bearing: inner ring, two ball rows with cage, and outer ring.
Cross-references on the ISO 1312 envelope, tapered bore, normal clearance: FAG 1312-K-TVH, NSK 1312K, NTN 1312K, Koyo 1312K, Timken 1312K, SNR 1312K.
