Availability:
2 in stock
Four-bolt flange ball bearing unit, 3/4 in bore, stainless steel housing and insert, set screw locking, food grade grease. Browning SF4S-S212, item 764091.
List Price
$47.94
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Browning |
|---|---|
| GTIN | 662460400631 |
| Model | SF4SS212 |
| ID | 3/4 in |
| Material | Stainless Steel |
|---|---|
| Series | 200 |
| Type | Four-Bolt Flange Ball Bearing Unit |
| Lubricant | NSF H1 food grade grease |
| Number Of Bolt Holes | 4 |
| Number Of Bolt Holes For Fasteners | 4 |
| Dynamic Load Rating | 2,611 lbf |
| Static Load Rating | 1,444 lbf |
| Rolling Elements | Ball |
| Bearing Type | Four-Bolt Flange Ball Bearing Unit |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Duty Type | Standard duty |
| Locking Device | Set Screw |
| Insert Outer Ring | Spherical |
| Harmonization Code | 8483.20.40.40 |
| Housing Material | 304 passivated stainless steel, investment cast |
| Expansion Type | Non-expansion (fixed) |
| Overall Width | 3.375 in |
| Housing Style | 4-bolt flange |
| Locking Method | Set screw |
| Mpn Variants | SF4S-S212, SF4SS212, SF4 SS 212, 764091 |
| Bearing Material | 440C stainless steel |
| Inner Ring Width | 2.4844 in |
Browning SF4S-S212 four-bolt flange ball bearing unit with a 3/4 in bore, set screw locking, a 304 stainless steel housing and a 440C stainless steel insert. Browning item number 764091. Standard duty, non-expansion (fixed).
SF4S — Browning stainless four-bolt flange unit, set screw locking.
S212 — stainless insert, 3/4 in bore (12 sixteenths).
Bore Diameter: 3/4 in (0.7500 in). Housing Style: 4-bolt flange. Locking Method: Set screw. Housing Material: 304 passivated stainless steel, investment cast. Bearing Material: 440C stainless steel inner and outer ring. Seal Type: Molded silicone single lip contact seal with 300 series stainless steel flinger. Lubricant: NSF H1 food grade grease. Expansion Type: Non-expansion (fixed). Duty Type: Standard duty. Dynamic Load Rating: 2,611 lbf. Static Load Rating: 1,444 lbf. Operating Temperature: -20 to 200 °F.
Housing Width: 3.380 in. Overall Width: 3.375 in. Inner Ring Width: 2.4844 in. Length Through Bore: 1-5/16 in. Number Of Bolt Holes: 4.
Browning item number 764091. Also written SF4S-S212, SF4SS212 and SF4 SS 212. Fits 3/4 in shafts.
What shaft size fits the Browning SF4S-S212?
A 3/4 in shaft, locked with set screws.
What is the SF4S-S212 made of?
A 304 stainless steel housing with a 440C stainless steel bearing insert.
What grease is in the SF4S-S212?
NSF H1 food grade grease.
