Flange mount ball bearing unit, 1-1/16 in bore, cast iron housing, eccentric locking collar, non-expansion, single row, new old stock. Fafnir RAK 1-1/16.
List Price
$37.32
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Fafnir |
|---|---|
| MPN | RAK 1-1/16 |
| Model | RAK 1 1/16 |
| ID | 1.0625 in |
| Series | RAK |
|---|---|
| Type | Flanged Mount Bearing |
| Base Number | RAK |
| Bore Shaft Size | 1.0625 in |
| Housing Style | Flange mount |
| Locking Method | Eccentric locking collar |
| Mpn Variants | RAK 1-1/16; RAK1-1/16; RAK-1-1/16; RAK1 1/16; RA1-1/16; RAK116 |
| Material | Cast iron |
| Rolling Elements | Ball |
| Bearing Type | Flange Mount Ball Bearing Unit |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Duty Type | Standard |
| Locking Device | Eccentric Collar |
| Housing Material | Cast Iron |
| Expansion Type | Non-expansion |
| Design Units | Imperial |
| Industry Terms | flange bearing unit; flange mount ball bearing; eccentric collar flange unit; 1-1/16 flange bearing; mounted bearing flange unit |
| Common Misspellings | Fafnir RAK1 1/16; Fanir RAK 1-1/16; Fafner RAK 1-1/16; Fafnir RAK 116 |
| Application Types | Conveyors; agricultural equipment; fans and blowers; light industrial machinery |
Fafnir RAK 1-1/16 is a flange mount ball bearing unit supplied with its eccentric locking collar. Bore / Shaft Size: 1.0625 in (1-1/16 in). Housing Style: Flange mount. Material: Cast iron housing. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Locking Method: Eccentric locking collar. Expansion Type: Non-expansion. Unit Quantity: 1 Pc. One complete flange unit with its insert and locking collar.
RA — Fafnir mounted unit with a self-aligning spherical-seat insert.
K — the eccentric locking collar seat on the extended inner ring.
1-1/16 — the shaft size in inches, which is how this range is numbered.
Bore / Shaft Size: 1.0625 in. Housing Style: Flange mount. Housing Material: Cast iron. Locking Method: Eccentric locking collar. Expansion Type: Non-expansion. Number Of Rows: 1. Design Units: Imperial.
Housing Style: Flange mount. The insert sits on a spherical seat inside the housing and takes up shaft misalignment. The eccentric locking collar fixes the unit to a plain shaft with a set screw. Non-expansion position: locates the shaft axially.
Written as RAK1-1/16, RAK 1-1/16, RAK-1-1/16, RA1-1/16 and RAK116.
Flange mount, cast iron housing.
1-1/16 in (1.0625 in).
Eccentric locking collar; the unit is non-expansion.
