NTN6214ZZC3EMDeep Groove Ball Bearing — 70 mm ID, 125 mm OD, 24 mm Width, Shields Both Sides, C3 Clearance, Polyrex EM Grease

Product Description

What this part is:

The NTN 6214ZZC3EM is a single-row deep groove ball bearing in the ISO 6214 size, shielded both sides and factory greased. Bore Diameter: 70 mm. Outside Diameter: 125 mm. Overall Width: 24 mm. Seal Type: Shields both sides. Internal Clearance: C3. Lubricant: Exxon Polyrex EM grease. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Unit Quantity: 1 Pc.

Decoding the designation:

62 — NTN 02 dimension series, the light-series deep groove section.

14 — bore code: 14 x 5 = 70 mm bore.

ZZ — steel shields on both sides.

C3 — radial internal clearance greater than normal.

L627 — NTN grease code for Exxon Polyrex EM, a polyurea grease.

Specifications:

Bearing Type: Deep Groove Ball Bearing. Closure Type: Shields both sides. Internal Clearance: C3. Lubricant: Exxon Polyrex EM grease. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Series: 6200.

Dimensions and mounting:

Bore Diameter: 70 mm. Outside Diameter: 125 mm. Overall Width: 24 mm.

Compatibility and replacement:

Same 70 x 125 x 24 mm envelope, double shields and C3 clearance: SKF 6214-2Z/C3, NSK 6214ZZC3, FAG 6214-2Z-C3 and Koyo 6214ZZC3.

Other forms of the number: 6214ZZC3EM, 6214ZZC3/L627, 6214ZZC3, 6214Z.

Frequently asked questions:

What size is the NTN 6214ZZC3EM?

Bore Diameter is 70 mm, Outside Diameter is 125 mm and Overall Width is 24 mm.

What does ZZ mean?

Steel shields on both sides.

What grease does it carry?

Exxon Polyrex EM grease, NTN grease code L627.
