This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Deep Groove Ball Bearing — 40 mm ID, 80 mm OD, 18 mm Width, Non-Contact Seals Both Sides, C3 Clearance$41.57
Ball Bearing — 40 mm ID, 80 mm OD, 18 mm Width, Metal Shields, Phenolic Separator, ABEC 5$59.48
Deep Groove Ball Bearing - Straight Bore, 40 mm ID, 62 mm OD, 12 mm Width, Rubber Contact Seals Both Sides, 69 Thin Section Series$27.51
Spindle Deep Groove Ball Bearing, 40 x 90 x 23 mm, ABEC 3 / P6$25.46| MFR / Brand | NSK |
|---|---|
| MPN | 6208-R-CE |
| Model | 6208R CE |
| Bearing Type | Ball Bearing, Open |
| ID | 40 mm |
| OD | 80 mm |
| Width | 18 mm |
| Material | 52100 Chrome Steel |
|---|---|
| Series | 6200 |
| Min Temp | -30 °C |
| Cage Type | Caged |
| Dynamic Load Rating | 29.1 kN / 6542 lbf |
| Static Load Rating | 17.8 kN / 4002 lbf |
| Precision Rating | ABEC 1 / P0 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 0.81 lbs |
| Cage Material | Steel |
| Limiting Speed | 10000 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | With Snap Ring |
| Harmonization Code | 8482.10.5028 |
| Internal Clearance | CN |
| Cross Reference 1 | SKF 6208-NR |
|---|---|
| Cross Reference 2 | FAG 6208-G |
