Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
2 in stock
Deep groove ball bearing, 100 x 150 x 24 mm, open on both faces. Single row, steel balls, CN internal clearance, metric 6020 boundary dimensions.
List Price
$106.96
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | MRC |
|---|---|
| Model | 120 K S / 6020 |
| Bearing Type | Ball Bearing, Open |
| ID | 100 mm |
| OD | 150 mm |
| Width | 24 mm |
| Source | MRC, Applied |
|---|---|
| Material | Bearing Steel |
| Series | 100KS |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Harmonization Code | 8482.10.50 |
| Internal Clearance | CN |
| Part Number | 120KS |
| Base Number | 6020 |
| Industry Terms | Deep groove ball bearing; radial ball bearing; single row ball bearing; open ball bearing |
| Common Misspellings | 120K5; 120 K S; MRC120KS; MRC 120 KS |
| Total Width | 24 mm |
| Overall Width | 24 mm |
| Bore Shaft Size | 100 mm |
| Mpn Variants | 120KS; 120-KS; 120 KS |
| Design Units | Metric |
| Bearing Material | Chrome steel |
| Cross Reference 1 | SKF 6020 |
|---|---|
| Cross Reference 2 | FAG 6020 |
| Cross Reference 3 | NSK 6020 |
| Cross Reference 4 | NTN 6020 |
| Cross Reference 5 | Timken 6020 |
| Cross Reference 6 | RHP 6020 |
| Cross Reference 7 | Koyo 6020 |
| Cross Reference 9 | SNR 6020 |
MRC 120KS single-row deep groove ball bearing. Bore / Shaft Size: 100 mm. Outside Diameter: 150 mm. Overall Width: 24 mm. Total Width: 24 mm. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Internal Clearance: CN. Bearing Material: Chrome steel. Design Units: Metric. Series: 100KS. Base Number: 6020. Part Number: 120KS. Unit Quantity: 1 Pc.
120 — bore code in the MRC 100KS light series, giving a 100 mm bore.
KS — single-row deep groove type ball bearing, MRC’s own symbol for the Conrad-assembled radial ball bearing.
Open — both faces uncovered, so the bearing takes lubricant directly from the housing.
One row of balls running in a deep groove raceway carries radial load together with thrust in either direction, which makes this the standard shaft bearing for electric motors, gear drives, pumps and blowers. Internal Clearance: CN. That is the standard radial clearance band, matched to a normal interference fit on the shaft at ambient running temperature.
Open faces allow oil or grease to circulate through the bearing from the housing and carry heat away with it, so an open execution runs faster than a shielded or sealed one of the same size.
Bore / Shaft Size: 100 mm, straight bore. Outside Diameter: 150 mm. Overall Width: 24 mm. This is the ISO 60-series light section for a 100 mm shaft, so the part fits any housing bored for a 6020.
Unit Quantity: 1 Pc. Single bearing, supplied as an individual unit.
The 100 x 150 x 24 mm open envelope is the ISO 6020. Open 6020 from other makers: SKF 6020, FAG 6020, NSK 6020, NTN 6020, Timken 6020, RHP 6020, Koyo 6020, SNR 6020. Searchable variants of the number: 120KS, 120-KS, 120 KS.
