Spindle Deep Groove Ball Bearing - Straight Bore, 65 mm ID, 140 mm OD, 33 mm Width, Open, ABEC 5 / P5, Machined Phenolic Cage$74.02
Ball Bearing — 65 mm ID, 140 mm OD, 33 mm Width, Single Shield$67.18
Sealed Deep Groove Ball Bearing – 65 mm ID x 100 mm OD x 18 mm, Contact Seals Both Sides, Snap Ring and Groove$42.06
Deep Groove Ball Bearing — 65 mm ID, 120 mm OD, 23 mm Width, ABEC 5, Open, CN Clearance$45.69| MFR / Brand | Fafnir |
|---|---|
| MPN | 3MM313WICRDUH |
| Model | 3 MM 313 WI CR DUH / 7313A5 7313A 7313E 7313ACD |
| Bearing Type | Ball Bearing, Open |
| ID | 65 mm |
| OD | 140 mm |
| Width | 33 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7300 |
| Condition | New – Open box |
| Lubricant | Oil |
| Preload | Heavy |
| Condition Note | Made In USA, New Old Stock |
| Min Temp | -30 °C |
| Cage Type | Phenolic |
| Dynamic Load Rating | 118 kN |
| Static Load Rating | 75 kN |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 4.60 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 25° |
| Mounting Arrangement | Universal |
| Limiting Speed | 10000 rpm |
| Cross Reference 1 | SKF 7313 ACD/P4DGC |
|---|---|
| Cross Reference 2 | NSK 7313A5TYNDUHP4 |
