Consolidated RLS-24 inch deep groove ball bearing, open: 3 in bore, 5-3/4 in OD, 1-1/16 in wide. Crosses to SKF RLS 24 and RHP LJ3. Unit Quantity: 1 Pc.
List Price
$202.88
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Consolidated |
|---|---|
| MPN | RLS-24 |
| Model | RLS 24 |
| Bearing Type | Ball Bearing, Open |
| ID | 3.0000 in (76.200 mm) |
| OD | 5.7500 in (146.050 mm) |
| Width | 1.0625 in (26.988 mm) |
| Mpn Variants | RLS-24, RLS24, RLS 24, LJ3 |
|---|---|
| Series | RLS |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Industry Terms | inch deep groove ball bearing 3 in bore; RLS series ball bearing; 3 x 5-3/4 in ball bearing |
| Common Misspellings | Consolidated RLS 24; Consolidated RLS24; Consolodated RLS-24; Consolidated RSL-24 |
| Closure Type | Open |
| Cross Reference 1 | SKF RLS 24 |
|---|---|
| Cross Reference 2 | RHP LJ3 |
Consolidated RLS-24 single-row inch deep groove ball bearing, open. Unit Quantity: 1 Pc.
RLS — inch-dimension light series deep groove ball bearing.
24 — size code for the 3 in bore, 5-3/4 in OD, 1-1/16 in wide envelope.
Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Closure Type: Open. Series: RLS. Unit Quantity: 1 Pc.
Bore Diameter: 3.0000 in (76.200 mm). Outside Diameter: 5.7500 in (146.050 mm). Overall Width: 1.0625 in (26.988 mm).
SKF RLS 24 and RHP LJ3 are open single-row inch deep groove ball bearings in the same 3 x 5-3/4 x 1-1/16 in size. MPN variants: RLS-24, RLS24, RLS 24, LJ3.
Bore Diameter: 3.0000 in (76.200 mm). Outside Diameter: 5.7500 in (146.050 mm). Overall Width: 1.0625 in (26.988 mm).
Open. Closure Type: Open.
SKF RLS 24 and RHP LJ3, both in the same 3 x 5-3/4 x 1-1/16 in size.
