Angular Contact Ball Bearing - Straight Bore, 60 mm ID, 95 mm OD, 18 mm Width, Open, 15° Contact Angle, Medium Preload, ABEC 7 / P4$250.85| MFR / Brand | SNR |
|---|---|
| MPN | 7012HVDUJ74 |
| Model | 7012A 7012 E T DUL P4 / 3MM9112WI CR DUL / 7012 H V DU J74 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 60 mm |
| OD | 95 mm |
| Width | 18 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7000 |
| Lubricant | Oil/Grease |
| Preload | Light |
| Min Temp | -30 °C |
| Cage Type | Phenolic |
| Dynamic Load Rating | 31.0 kN |
| Static Load Rating | 28.0 kN |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 0.95 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 25 ° |
| Mounting Arrangement | Universal |
| Limiting Speed | 15000 rpm |
| Cross Reference 1 | SKF 7012 ACDGA/P4A |
|---|---|
| Cross Reference 2 | FAG B7012-E-T-P4S-UL |
Discover Precision with SNR 7012HVDUJ74 Angular Contact Ball Bearings
Upgrade your machinery with the exceptional SNR 7012HVDUJ74 Bearing, measuring 60x95x18 mm. This high-performance angular contact ball bearing is exclusively manufactured in France to meet strict quality standards, ensuring optimal functionality and durability across various applications.
Type: Angular Contact Ball Bearing
Model: 7012A 7012 E T DUL P4 / 3MM9112WI CR DUL / 7012 H V DU J74
MPN: 7012HVDUJ74
Width: 18 mm
Engineered for precision, these bearings excel in applications requiring robust performance under load. They deliver reliability and efficiency, ensuring your machinery operates at peak performance.
